D-TECH Fusion Splicer SM
.jpg)
Price: Rs 160000.00
D-TECH Fusion Splicer
Specifications
| Category | Specification |
|---|---|
| Fiber Types | SMF (G.652), MMF (G.651), DSF (G.653), NZDSF (G.655), BIF (G.657) |
| Fiber Diameter | Cladding: 80–150μm, Coating: 100–3000μm |
| Cleave Length | 5–16mm (<250μm coating), 10mm (0.25–3mm coating) |
| Splice Loss | SMF: 0.03dB, MMF: 0.02dB, DSF: 0.05dB, NZDSF: 0.05dB, BIF: 0.03dB |
| Return Loss | > 60dB |
| Splicing Time | 7 sec (Quick), 10 sec (Auto) |
| Heating Time | 15–18 sec (40mm / 60mm sleeves) |
| Battery Cycles | Approx. 400 splice & heat cycles |
| Fiber View | 2 CMOS cameras, 240X (X/Y single), 160X (dual axis) |
| Tension Test | 1.96–2.25N |
| Protection Sleeve | 60mm, 40mm and more |
| Operation Mode | Manual / Auto |
| Splice Programs | Max 304 (18 preset, 286 editable) |
| Heating Programs | Max 104 (11 preset, 93 editable) |
| Data Storage | 30,000 splice records |
| Fiber Holder | 3-in-1 (250μm, 900μm, 2–3mm cable) |
| Auto Functions | Arc, Motor, Electrodes, Self-test |
| Display | 4.3” Touch Screen LCD |
| Size | 120 × 130 × 154 mm |
| Weight | 1.95 kg (with battery), 1.65 kg (without) |
| Ports | USB 2.0, SD Card |
| Power Supply | DC 10–15V / AC 100–240V |
| Battery | Li-ion 11.1V, 6800mAh |
| Operating Condition | -20~50°C, 0–95% RH, up to 6000m altitude |
| Electrode Life | 5000 arcs |
