GPON OLT STICK
Price: Rs 19115.04
HSGQ GPON OLT Stick DT:32 – SFP GPON OLT Module
The HSGQ GPON OLT Stick TS-GB32 is a compact SFP-based GPON OLT module designed for switches, routers, gateways, and other Ethernet devices. It provides a simple, flexible, and cost-effective GPON solution for FTTH and FTTR deployments.
Key Features
| Feature |
Description |
| Plug and Play |
Easy installation with minimal configuration |
| Management |
Supports management and rate limiting functions |
| GPON Auto Configuration |
Supports automatic GPON service configuration |
| ONU Capacity |
Supports up to 32 ONUs with automatic registration |
| MAC Switching |
Supports MAC switching within optical networks |
| QoS |
Supports business flow classification and QoS |
| Applications |
Suitable for industrial parks, hotels, apartments, shopping malls, schools, and FTTR networks |
Core Specifications
| Parameter |
Specification |
| Structure |
MSA SFP |
| GPON Rate |
2.5 Gbps Downstream / 1.25 Gbps Upstream |
| TCONT Number |
256 |
| Output Power |
-2.25db |
| Maximum Split Ratio |
1:32 |
| Maximum Transmission Distance |
10 km |
| FEC |
Supported |
| DBA |
Dynamic Bandwidth Allocation Supported |
| OMCI |
Supported |
| Inter-Optical Network Switching |
Supported |
| Rogue ONU Detection |
Supported |
Environmental & Power
| Parameter |
Specification |
| Operating Temperature |
-40°C to +85°C |
| Power Consumption |
< 3W |
