40G Transmission Over a Single Fiber Core Using DWDM (Mux & Demux Solution)
→ Using DWDM Mux and Demux, we can achieve up to 40G capacity over a single fiber core by combining four 10G DWDM channels.
→ D-TECH provides DWDM solutions that allow multiple high-speed links to run over one fiber core, ideal when fiber resources are limited.
Why DWDM is Needed
→ In many existing networks, fiber cores are already busy, and no extra core is available for expansion.
→ Instead of laying new fiber, DWDM enables easy upgrades from 10G to 20G, 30G, or 40G using the same fiber.
→ This solution is suitable for both current expansion and future-ready networks.
Future Upgrade Capability
→ The same DWDM infrastructure can be upgraded to 100G in the future.
→ Simply replace 10G DWDM SFP+ with 25G DWDM SFP28 or 100G DWDM modules.
→ No change is required to the fiber or Mux/Demux equipment.
Costing (Indicative – Nepal Market)
→ DWDM MUX, 4CH, 8 Wavelengths, 1/4 LGX Box : NPR 22,000
→ DWDM DEMUX, 4CH, 8 Wavelengths, 1/4 LGX Box : NPR 22,000
→ 1U Rack with 4 Slots : NPR 9,000
Total without DWDM SFP (A) : 53,000
SFP should be selected as per requirement.
→ 10G DWDM SFP+ (40 km) (B) : NPR 17,000 / pc *8pc=NPR 136000
Total : (A)+(B)= 189000
→ 10G DWDM SFP+ (80 km) (C): NPR 22,000 / pc *8pc= NPR 176000
Total : (A)+(C)= 229,000
There are other channel that is 8channel or 16 Chanel of Mux and Demux
