Fiber Drop Cable SC UPC to SC APC
Visit the D-TECH Store
-1%
Rs
1,971
.45
M.R.P.: Rs 1,986.16
Exclusive of all taxes
.jpg)
.jpg)
Technical Details
| Weight | 5kg |
| More Details | 1 Full Carton contains 6 Rolls |
| Lead Time | China to Nepal 35-45Days |
| Warranty | 1 Year |
Rs 1,971.45
-1%
M.R.P. Rs 1,986.16
Excl. taxes
| Min. Order | Unit Price |
|---|---|
| 1 Roll(1) | Rs 1,971.45 |
Trade Assurance
Built-in order protection
In Stock
FREE Delivery on eligible orders
Select a city to check delivery
Supplier Info
D-TECH
Verified Supplier
4.8 / 5.0 Response Rate
7-Day Returns
if defective or damaged
if defective or damaged
Warranty
Seller warranty (if applicable)
Seller warranty (if applicable)
Secure Payment
Multiple options available
Multiple options available
PRE-CONNECTORIZED FTTH DROP CABLE
FTTH Drop Cable SC/UPC to SC/APC
1 Core • G.657A1 Bend-Insensitive Fiber • Steel Reinforced • Available from 30M to 300M
The FTTH Drop Cable SC/UPC to SC/APC is a pre-connectorized single-mode optical fiber cable designed for fast and reliable FTTH customer installation. It uses G.657A1 bend-insensitive fiber with steel wire reinforcement and factory-installed SC/UPC and SC/APC connectors for stable optical performance and easy field deployment.
FIBER TYPE
G.657A1
CORE COUNT
1 Core
CONNECTORS
UPC → APC
LENGTH OPTIONS
30M–300M
Key Features
✓
G.657A1 bend-insensitive single-mode fiber
✓
Factory-installed SC/UPC to SC/APC connectors
✓
Ready for direct FTTH customer installation
✓
Steel wire reinforced cable construction
✓
Suitable for indoor and outdoor drop deployment
✓
Multiple ready-made cable lengths
Connector Configuration
CONNECTOR A
SC/UPC
Blue Connector
CONNECTOR B
SC/APC
Green Connector
Cable Structure
| Parameter | Details |
|---|---|
| Fiber Type | G.657A1 Bend-Insensitive Fiber |
| Number of Fibers | 1 Core |
| Strength Member | 2 × 0.45 mm Steel Wires |
| Messenger Wire | 1.0 mm Galvanized Steel, 7 × 0.33 mm Strands |
| Cable Dimension | 2.0 × 5.0 mm |
| Cable Weight | 1 kg/km ±5% |
| Cable Print | D-TECH / Production Date |
Mechanical Performance
SHORT-TERM TENSILE
600 N
LONG-TERM TENSILE
300 N
SHORT-TERM CRUSH
2200 N
LONG-TERM CRUSH
1000 N
| Parameter | Value |
|---|---|
| Minimum Bend Radius – Static | 20 mm |
| Minimum Bend Radius – Dynamic | 40 mm |
| Installation Temperature | -10°C to +40°C |
| Operating Temperature | -40°C to +60°C |
Connector Specifications
| Parameter | SC/UPC | SC/APC |
|---|---|---|
| Fiber Mode | Single Mode G.657A1 | |
| Cord Type | Simplex | |
| Insertion Loss | ≤ 0.3 dB | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB | ≥ 55 dB |
Available Lengths
30M
50M
75M
100M
150M
200M
300M
Applications
FTTH Installation
ISP Customer Connection
ONU Installation
Home Fiber Internet
Building Fiber Cabling
Outdoor Drop Deployment
Installation Advantage
The cable is supplied with factory-installed
SC/UPC on one side and SC/APC on the other side,
helping reduce field connectorization work and allowing faster FTTH deployment.
