Technical Specifications
Parameter
Specification
Product Type
Fiber Optic Patch Cord (Simplex)
Connector Type
FC/UPC to SC/UPC
Fiber Type
Single Mode (OS2)
Core / Cladding
9/125 µm
Cable Diameter
3.0 mm
Polish Type
UPC
Insertion Loss
≤ 0.3 dB
Return Loss
≥ 50 dB
Repeatability
≤ 0.1 dB
Durability
≥ 1000 mating cycles
Operating Temperature
-20°C to +70°C
Storage Temperature
-40°C to +85°C
Tensile Strength
≥ 100 N
Jacket Material
PVC / LSZH (Optional)
Cable Color
Yellow
