12 Port 10G L3 Managed Industrial Switch, support 12 SFP+ port, 1 Console port., providing complete security policy, perfect QoS policy and rich VLAN function, easy to manage and maintain, meeting the networking and access requirements of enterprises, communities, hotels, office networks and campus network.
Key Feature
- Support IEEE 802.1d、IEEE 802.1w、IEEE 802.1s、 IEEE 802.1p、IEEE 802.3、IEEE 802.3u、IEEE 802.3x、 IEEE 802.3z、IEEE 802.3ab、IEEE 802.3ae Standard
- L3 Management, Support DHCP Server, DHCP Snooping, DHCP Relay, Static Routing, RIP and OSFP
- Support RSTP/MSTP n Support VLAN function, Port VLAN, translation and Qin-Q
Hardware Specication
| Item | HSGQ-7912 |
| Interface |
| Poet | 12*10G SFP+ |
| Console | 1*RS-232 （115200,8,N,1） |
| Switch Property |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1x |
| Forwarding Modes | store and Forward |
| Packet Buffer | 12Mbit |
| MAC Table | 32k |
| Switching Capacity | 240Gbps / non-blocking |
| Packet Forwarding Rate | 179Mpps |
| Jumbo Frame | 12kB |
| Power Supply |
| Input Voltage | AC100V-240V，50Hz/60Hz |
| Power Consumption | 40W |
| Reliability |
| ESD Protection | 8kV Contact Discharge, 15kV Air Discharge, Standard: IEC61000-4-2 |
| MTBF | 100000 h |
| MTBF Standards | Telcordia SR-332，25 |
| Operating Temperature | -40℃~75℃ |
| Storage Temperature | -40℃~85℃ |
| Operating Humidity | 5%~95%(Non-condensation) |
| Physical Parameter |
| Led Indicators | - 1*power supply indicators
- 1*system working indicator
- 12*optical port status ind
|
| Reset Button | Short press to restart the switch, long press ＞7s to initialise the system |
| Dimensions (W*D*H) | 445*193*44mm |
| Net Weight | 1.7 k |
| Material | Aluminium |
Download HSGQ-7912 User Manual Download HSGQ-Switch CLI Manual Download HSGQ-7912 : Data sheet in PDF File |
|
