ADSS Tension Clamp Rods
Variant Specifications
Single Layer Tension Clamp
The Single Layer Tension Clamp is a preformed dead-end grip designed for anchoring and terminating ADSS aerial fiber optic cables. It provides firm cable holding performance while distributing mechanical pressure evenly along the cable surface.
Manufactured from aluminium-clad steel, the clamp offers high mechanical strength, corrosion resistance, and long-term outdoor reliability. It is suitable for ADSS cables with diameters from 10 mm to 15 mm and can be selected for spans of 100 m, 200 m, 300 m, 400 m, 500 m, and other project requirements.
Quick Specifications
Key Features
- Single-layer preformed tension clamp
- Designed for ADSS aerial fiber optic cable fixing
- Suitable for cable diameters from 10 mm to 15 mm
- Available for multiple aerial span requirements
- Manufactured from aluminium-clad steel
- Preformed dead-end grip structure
- High mechanical holding performance
- Corrosion-resistant silver finish
- Suitable for ADSS and OPGW cable fittings
- Designed for long-term outdoor installation
Technical Specifications
| Parameter | Technical Specification |
|---|---|
| Product Name | Single Layer Tension Clamp |
| Application | ADSS Aerial Fiber Optic Cable Fixing and Termination |
| Suitable Cable Diameter | 10–15 mm |
| Span Options | 100 m, 200 m, 300 m, 400 m, 500 m, etc. |
| Material | Aluminium-Clad Steel |
| Manufacturing Process | Casting or Forged |
| Structure | Preformed Dead-End Grip |
| Rated Load | 120 kN |
| Usage | ADSS / OPGW Cable Fittings |
| Color | Silver |
| Installation Environment | Outdoor Aerial Fiber Optic Networks |
Available Span Options
Applications
ADSS Cable Termination
Used for securely anchoring ADSS fiber optic cables at terminal and tension poles.
Telecommunication Networks
Suitable for aerial backbone, distribution, FTTH, and FTTx fiber networks.
Power Utility Networks
Supports ADSS and OPGW cable hardware installation along utility routes.
Long-Span Installation
Available for different pole spans according to cable and project requirements.
Installation Recommendation
Select the tension clamp according to the exact ADSS cable diameter, span length, cable tensile strength, route conditions, wind load, ice load, and pole configuration. Ensure the preformed rods are installed evenly around the cable without overlapping or damaging the cable jacket. The clamp's rated load should be confirmed against the final project and cable design before installation.
