200G QSFP56 Active Optical Cable (AOC) – OM3 / OM4
The 200G QSFP56 Active Optical Cable (AOC) is a high-speed optical interconnect solution designed for AI infrastructure, cloud computing, hyperscale data centers, enterprise networking, telecom backbone, and HPC environments.
This cable integrates optical transceivers and multimode fiber into a single assembly, delivering stable 200Gbps high-speed transmission, low latency, excellent signal integrity, and reduced power consumption for short-distance optical connectivity applications.
Key Features
| Supports 200Gbps ultra-high-speed transmission |
| QSFP56 to QSFP56 Active Optical Cable |
| Supports OM3 / OM4 multimode fiber optic cable |
| 850nm VCSEL optical transmission technology |
| PAM4 modulation format for high-speed communication |
| Built-in TX & RX CDR for stable signal performance |
| Low latency and low power consumption design |
| Supports DDM / DOM digital diagnostics monitoring |
| Flexible and lightweight optical cable structure |
| Suitable for switches, routers, servers, AI clusters, and storage systems |
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | 200G QSFP56 Active Optical Cable (AOC) |
| Form Factor | QSFP56 to QSFP56 |
| Maximum Data Rate | 200Gbps |
| Data Rate Per Lane | 50Gbps × 4 Channels |
| Cable Length | 1M to 100M |
| Cable Type | OM3 / OM4 Multimode Fiber |
| Wavelength | 850nm |
| Transmitter Type | VCSEL Laser |
| Receiver Type | 850nm PIN |
| Modulation Format | PAM4 |
| CDR | TX & RX Built-in CDR |
| DDM / DOM | Supported |
| Maximum Power Consumption | < 5W Per End |
| Minimum Bend Radius | 30mm |
| Jacket Material | OFNP / LSZH |
| Operating Temperature | 0°C to 70°C |
| Compliance | QSFP56 MSA, IEEE 802.3cd, RoHS |
Applications
| 200G Ethernet Networks |
| AI & GPU Cluster Networking |
| Cloud Computing Infrastructure |
| Hyperscale Data Centers |
| High Performance Computing (HPC) |
| Enterprise Backbone Connectivity |
| High-Speed Storage Networks |
| Switch-to-Switch and Server Connectivity |
Note: Maintain proper cable routing and minimum bend radius during installation to ensure stable 200G optical transmission performance and long cable lifespan.
