Optical Fiber Cable 24 core FRP

Name: Optical Fiber Cable 24 core FRP
Brand: D-TECH
SKU: PR-002004
Availability: InStock

Visit the D-TECH Store

0.0

0 ratings

Contact for Quote

Variation: GYFXY 8mm-CH

GYFXY 8mm-CH

GYFXY 7mm-CH

Download Datasheet Save

SKU: #127 Category: Optical Fiber Cable and Accessories

Contact for Price

Pricing based on order quantity

Trade Assurance Built-in order protection

In Stock

FREE Delivery on eligible orders

Deliver to

Select a city to check delivery

Supplier Info

D-TECH

Verified Supplier

4.8 / 5.0 Response Rate

7-Day Returns
if defective or damaged

Warranty
Seller warranty (if applicable)

Secure Payment
Multiple options available

24 CORE • SINGLE MODE • G.652D

24 Core Optical Fiber Cable

Outdoor Single-Mode Fiber Cable • PBT Loose Tube • FRP Strength Member • 2400D Yarn • MDPE Outer Sheath

Product Overview

The 24 Core Optical Fiber Cable is designed for reliable outdoor optical transmission in ISP, telecom, backbone, enterprise and fiber infrastructure networks.

It uses ITU-T G.652D single-mode optical fiber, PBT loose tube construction, FRP strength members, 2400D reinforcement yarn and an MDPE outer sheath for dependable mechanical and environmental performance.

FIBER COUNT

24 Core

FIBER STANDARD

G.652D

STRENGTH MEMBER

FRP

STANDARD LENGTH

2000M

Key Features

✓ 24 Core Single-Mode Optical Fiber

✓ ITU-T G.652D Fiber Standard

✓ PBT Loose Tube Construction

✓ Non-Metallic FRP Strength Member

✓ 2400D Reinforcement Yarn

✓ Durable MDPE Outer Sheath

✓ Low Optical Attenuation

✓ Suitable for Outdoor Fiber Networks

Fiber Color Code

Standard 12-color fiber identification sequence. For 24-core construction, the color sequence is repeated according to the cable's loose-tube arrangement.

1. Blue

2. Orange

3. Green

4. Brown

5. Gray

6. White

7. Red

8. Black

9. Yellow

10. Violet

11. Pink

12. Aqua

Cable Construction

Component	Parameter	Specification
Optical Fiber	Fiber Standard	Single Mode ITU-T G.652D
Loose Tube	Material	PBT
Loose Tube	Diameter	1.9 mm
Strength Member	Material	FRP
FRP	Diameter	0.8 mm
Reinforcement	Yarn	2400D Yarn
Outer Sheath	Material	MDPE
Cable Diameter	Nominal	7 / 8 mm (±0.3 mm)

Mechanical Performance

TENSILE LOAD

400 / 1000 N

CRUSH RESISTANCE

300 / 1000 N

per 100 mm

STATIC BEND

10 × OD

INSTALLATION BEND

20 × OD

G.652D Optical Performance

Parameter	Specification
Fiber Material	Doped Silica
Attenuation @ 1310nm	≤ 0.36 dB/km
Attenuation @ 1383nm	≤ 0.32 dB/km
Attenuation @ 1550nm	≤ 0.22 dB/km
Attenuation @ 1625nm	≤ 0.30 dB/km
Point Discontinuity	≤ 0.05 dB
Cable Cut-Off Wavelength	≤ 1260 nm
Zero-Dispersion Wavelength	1300 – 1324 nm
Zero-Dispersion Slope	≤ 0.093 ps/(nm²·km)
Chromatic Dispersion @ 1288–1339nm	≤ 3.5 ps/(nm·km)
Chromatic Dispersion @ 1271–1360nm	≤ 5.3 ps/(nm·km)
Chromatic Dispersion @ 1550nm	≤ 18 ps/(nm·km)
Chromatic Dispersion @ 1625nm	≤ 22 ps/(nm·km)
PMDQ	≤ 0.2 ps/km^1/2
Mode Field Diameter @ 1310nm	9.2 ± 0.4 μm
Core / Cladding Concentricity	≤ 0.5 μm
Cladding Diameter	125.0 ± 0.7 μm
Cladding Non-Circularity	≤ 1.0%
Primary Coating Diameter	245 ± 10 μm
Proof Test	100 kpsi (0.69 GPa), 1%

Environmental Performance

OPERATING

-40°C to +60°C

INSTALLATION

-20°C to +50°C

STORAGE / TRANSPORT

-50°C to +70°C

Packing & Delivery

Parameter	Details
Packing Type	Wooden Drum / Coil Type
Standard Length	2000 m ±5%
Drum Protection	Plastic buffer sheet with strong protective wooden battens
Testing Reserve	Minimum 1 m cable end reserved for testing
Permitted Single Length	Not less than 90% of standard length where applicable

Applications

ISP Networks Telecom Backbone FTTx Networks Enterprise Fiber Campus Networks Outdoor Fiber Distribution Backbone Infrastructure

24 Core Cable Configuration

The supplied specification contains a conflicting entry showing “12” in the optical-fiber core field while the product is identified as 24 Core. Confirm the exact loose-tube arrangement and fibers per tube before publishing that specific construction value.
