DWDM MUX AND DEMUX (Red 21-32) & (Blue 42-45/49-56)1U RACK WITH 1 LGX BOX 12CH BIDI SINGLE FIBER (SIDE A )

0.0

0 ratings

-4% Rs 75,557 .80

M.R.P.: ~~Rs 78,408.00~~

Exclusive of all taxes

Technical Details

Delivery Time (if import required)	143-TRIAL-CH-NP 15-20Days 88
Warranty	1 Year
Country of Origin	China
Weight	1.180 Kg

Download Datasheet Save

SKU: #1488 Category: OFC Passive Devices

Rs 75,556.80 -4%

M.R.P. ~~Rs 78,408.00~~

Excl. taxes

Min. Order	Unit Price
1 Piece	Rs 75,556.80

Trade Assurance Built-in order protection

In Stock

FREE Delivery on eligible orders

Deliver to

Select a city to check delivery

Supplier Info

D-TECH

Verified Supplier

4.8 / 5.0 Response Rate

7-Day Returns
if defective or damaged

Warranty
Seller warranty (if applicable)

Secure Payment
Multiple options available

DWDM MUX & DEMUX (Side A) – 1U Rack with LGX Box, 12CH BIDI Single Fiber

Parameter	Specification
Wavelength	C21–C28 / C42–C45 / C50–C56
Channel Spacing	100 GHz (0.8 nm)
Channel Passband	±0.11 nm
Technology	TFF (Thin Film Filter)
Insertion Loss	≤ 3.8 dB
Center Wavelength Accuracy	±0.05 nm
Return Loss	≥ 45 dB
Directivity	≥ 45 dB
Polarization Mode Dispersion	≤ 0.1 ps
Polarization Dependent Loss	≤ 0.3 dB
Channel Isolation	Adjacent ≥ 30 dB Non-adjacent ≥ 45 dB
Temperature	Operating: -20°C to +70°C Storage: -40°C to +85°C
Net Weight	3.5 kg
Dimensions (H × W × D)	44 × 440 × 230 mm
