Fiber Distribution Hub FDH Outdoor
| Warranty | 1 Year 206 |
| Size | 550mm (L) × 310mm (W) × 1030mm (H) 280 |
| Country of Origin | China |
| Delivery Time (if import required) | 30-40Days by Road 90 |
| Min. Order | Unit Price |
|---|---|
| 1 Set(1) | Rs 74,707.97 |
if defective or damaged
Seller warranty (if applicable)
Multiple options available
Fiber Optic Cross Cabinet
The Fiber Optic Cross Cabinet is a high-capacity outdoor fiber distribution cabinet designed for connecting trunk optical fiber cables with distribution fiber cables. It integrates fiber splicing, storage, cable routing, protection, and optical distribution into a single enclosure, making it ideal for modern FTTH, FTTx, CATV, ISP, and telecommunication networks.
Built with a durable weather-resistant construction, the cabinet provides secure cable management while supporting SC/UPC adapters. The 30° angled adapter design minimizes laser exposure and simplifies maintenance, making it suitable for telecom operators, data centers, enterprise campuses, and outdoor fiber distribution points.
Quick Specifications
Key Features
- High-quality weather-resistant cabinet construction
- Supports fiber splicing, storage and distribution
- 144-port maximum capacity
- 12 ports per splice tray
- Compatible with SC/UPC adapters
- 30° angled adapter design reduces laser exposure
- Easy operation and maintenance
- Excellent cable routing and protection
- Suitable for FTTH, CATV and Telecom networks
- Professional outdoor fiber distribution solution
General Specifications
| Parameter | Specification |
|---|---|
| Product Type | Fiber Optic Cross Cabinet |
| Dimensions (L × W × H) | 550 × 310 × 1030 mm |
| Capacity | 144 Ports |
| Ports per Tray | 12 Ports |
| Adapter Type | SC/UPC |
| Adapter Design | 30° Angled Adapters |
| Accessories | Heat Shrinkable Protection Sleeves Included |
| Operating Temperature | -40°C to +60°C |
| Relative Humidity | ≤95% (40°C) |
| Insulation Resistance | ≥ 2 × 10⁴ MΩ / 500V DC |
Applications
Telecommunication Networks
Ideal for fiber backbone distribution and telecom access networks.
CATV Networks
Provides secure optical fiber distribution for cable TV infrastructure.
FTTH / FTTx
Suitable for outdoor fiber distribution and access network deployment.
ISP & Enterprise Networks
Perfect for internet service providers, campuses and industrial fiber networks.
Installation Recommendation
For optimal performance, install the Fiber Optic Cross Cabinet on a stable foundation in a secure outdoor location. Ensure proper fiber routing, splice protection, and cable management during installation. Regular inspection and maintenance are recommended to maintain reliable optical network performance in FTTH, CATV, and telecommunication applications.
