Optical fiber Cable 6 core FRP 6MM (Drum)
Loading variant details...
Variant Specifications
Request a Quote
Contact us for pricing details.
The 6-Core FRP 6mm Optical Fiber
Cable is designed to provide reliable and efficient data transmission for
various networking applications. Its construction features six single-mode
fibers compliant with G.652D standards, ensuring low attenuation and high-speed
data transfer.
Technical Parameters:
- Fiber Type:
Single Mode Fiber G.652D
- Number of Fibers:
6
- Cable Diameter:
Approximately 6mm
- Attenuation:
- @1310nm: ≤0.36 dB/km
- @1550nm: ≤0.22 dB/km
- Strength Members:
Two Fiber Reinforced Plastic (FRP) rods embedded in the HDPE sheath
- Loose Tube:
1
- Fiber Colors:
Blue, Orange, Green, Brown, Grey, White.
Key Features:
- Moderate Fiber Count:
Contains six fibers, suitable for applications requiring moderate data
channels within a single cable.
- Robust Construction:
Incorporates FRP rods as strength members, enhancing durability and resistance
to physical stresses.
- Environmental Resilience: The HDPE outer sheath offers protection against
moisture, temperature variations, and UV radiation.
- Low Signal Loss:
Engineered for minimal attenuation, ensuring efficient data transmission
over long distances.
Product Advantages:
- Enhanced Durability:
The FRP strength members provide superior tensile strength, reducing the
risk of cable damage during installation and operation.
- Versatile Applications: Suitable for both outdoor and indoor installations,
including telecommunications, data transmission, and network
infrastructure projects.
- Cost-Effective:
Combines high performance with durability, offering a cost-efficient
solution for expanding network infrastructures.
- Ease of Installation:
The cable's design facilitates straightforward handling and installation,
reducing labor costs and time.
This optical fiber cable is ideal for telecommunications, data centers, and other network environments requiring reliable and efficient data transmission.
Product Overview of Optical fiber Cable 6 core FRP
6MM (Drum):
Core Count: 6 cores, indicating the number of individual optical
fibers within the cable.
FRP Strength Member: Incorporates Fiber Reinforced Plastic for enhanced
durability and resistance to physical stresses.
Diameter: 6mm, specifying the overall thickness of the cable, ideal
for a balance between flexibility and protection.
Packaging: Drum, suggesting that the cable is wound on a drum for
easy deployment over long distances.
Application: Suitable for both outdoor and indoor use, typically in
telecommunications, data transmission, and network infrastructure projects.
In the realm of
telecommunications and network infrastructure, the choice of optical fiber
cable is pivotal to achieving high performance and reliability. A key feature
of such a cable is its Core Count,
which, in this case, stands at 6
cores. This denotes the number of individual optical fibers contained
within the cable, each capable of transmitting data at high speeds. This 6-core
configuration strikes an optimal balance between capacity and size, making it
suitable for a variety of applications, from high-speed internet connections to
secure data transmission in both commercial and residential settings.
Another crucial aspect of
this optical fiber cable is the incorporation of FRP
(Fiber Reinforced Plastic) as a Strength
Member. This innovative design choice significantly enhances the
cable's durability and provides superior resistance to physical stresses such
as bending, twisting, and pulling. The FRP Strength Member ensures that the cable
can withstand harsh environmental conditions and physical handling during
installation and maintenance, thereby extending the cable's lifespan and
maintaining the integrity of the data transmission.
The Diameter of the cable is another
critical specification, measured at 6mm.
This dimension is carefully chosen to offer an ideal balance between
flexibility and protection. At 6mm, the cable is thick enough to provide robust
protection against external damages, such as cuts or abrasions, while remaining
flexible enough to be easily routed through tight spaces and conduits. This
makes it an excellent choice for installations that require both durability and
ease of handling.
Packaging plays a significant role in the handling and deployment of
optical fiber cables, especially over long distances. This particular cable
comes wound on a Drum, a
practical solution that facilitates easy, efficient, and safe deployment. The
drum packaging not only protects the cable during transit but also simplifies
the installation process, allowing for quick and hassle-free unwinding and
laying of the cable over vast distances. This method of packaging is
particularly beneficial for large-scale telecommunications and network
infrastructure projects.
When it comes to Application, this optical fiber cable
is designed to be versatile, suitable for both outdoor
and indoor use. Its robust construction and high-quality materials
make it an ideal choice for a wide range of applications, including
telecommunications, data transmission, and network infrastructure projects.
Whether it's being used to connect buildings in a campus setting, run through
conduits in a residential complex, or laid across rugged terrains, this cable
ensures reliable and uninterrupted data transmission.
The cable's design and
specifications make it especially suitable for projects that require high data
transmission speeds, reliability, and durability. The 6-core configuration,
combined with the strength and flexibility provided by the FRP Strength Member
and the practical 6mm diameter, make it a top choice for professionals in
telecommunications and networking.
Fiber Optic Cable Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Number of Cores | 12 Core |
| Diameter | 6 mm | |
| Cable Length | 1 km | |
| Voltage | 12V | |
| Coil Length | 2000 m | |
| Fiber Details | Fiber Type | Single Mode Fiber (G.652D) |
| Fibers per Loose Tube | 6F | |
| Fiber Colors | Blue, Orange, Green, Brown, Grey, White | |
| Fiber Attenuation | @1310 nm | ≤0.36 dB/km |
| @1550 nm | ≤0.22 dB/km | |
| Strength Members | Material | 2 FRP Rods Embedded in HDPE Sheath |
| Size | 1 mm | |
| Loose Tube | Quantity | 1 No. |
| Material | PBTP | |
| Nominal Diameter | 1.9 mm | |
| Color | Natural | |
| Filling Compound | Thixotropic Jelly | |
| Outer Jacket | Material | HDPE |
| Color | Black | |
| Nominal Thickness | 2.1 mm | |
| Tensile Strength | (Not Specified) | Newton |
| Cable Dimensions | Nominal Diameter | 6 mm |
| Nominal Weight | 30 kg/km | |
| Standard Length | Available Lengths | 2000–3500 meters |
| Printing Details | D-Tech Trading | – |
