POE Media Converter 1G-2SC-8RJ45
Loading variant details...
Variant Specifications
-5.36% Rs5328.14
List Price:Rs5,328.14 now per pc(1)
Product Overview
The 1G PoE Media Converter (2SC +
8RJ45) is a compact, high- performance device that integrates Gigabit
Ethernet transmission with Power over Ethernet (PoE technology.
It features 2x SC fiber ports and 8x RJ45 Ethernet
ports with PoE output, allowing seamless fiber uplink with copper
downlink distribution in surveillance, wireless access, and industrial
networking environments.
Key
Features
1. 2 x 1000Mbps SC Fiber Ports (Single-mode or Multi-mode)
2. 8 x 10/100/1000Mbps RJ45 Ports with IEEE 802.3af/at PoE support
3. Supports PoE power output up to 30W per port,
max 120W total
4. Auto MDI/MDI-X and auto-negotiation for RJ45 ports
5. Plug-and-play, no software required
6. Fiber port supports long-distance transmission (up to 20km or
more, model-dependent)
7. Industrial-grade design for high durability
Technical Specifications
|
Specification |
Details |
|
Fiber
Ports |
2× SC
(1000Base-LX/FX, Singlemode or Multimode) |
|
Ethernet
Ports |
8× RJ45 (10/100/1000
Mbps, Auto-Negotiation) |
|
Total
PoE Budget |
Max 120W (varies by
power supply) |
|
Fiber
Transmission |
20km typical (SM);
2km (MM) |
|
Wavelength |
1310nm / 1550nm |
|
Power
Supply |
External AC 100 |
|
Input
Voltage |
48~57V DC |
|
Operating
Temperature |
-10°C to +55°C |
|
Storage
Temperature |
-40°C to +85°C |
|
Humidity |
5% to 95% RH
(non-condensing) |
|
Housing |
Metal, fanless
design |
|
Dimensions |
Approx. 220mm ×
150mm × 45mm |
|
Installation |
Desktop or
wall-mount |
|
Certifications |
CE, FCC, RoHS |
Applications
1. IP surveillance and PoE camera deployment
2. Wireless AP backhaul
3. Fiber to Ethernet network conversion
4. Enterprise and campus networks
5. Industrial and smart building automation
