100G QSFP28 DCO DWDM C-Band LC Duplex SMF
CH 37
Brand:
D-TECH
Variant Specifications
Warranty:
Weight:
Country of Origin:
More Details:
Import Lead Time:
Package:
1% OFF
Rs 346,207.1000
List: Rs 350,307.9000
100G QSFP28 DCO DWDM C-Band Coherent Transceiver – CH 37
| Category | Specification |
|---|---|
| General Specifications | |
| Model | QSP-100COTU |
| Product Type | 100G QSFP28 DCO Coherent Transceiver |
| Form Factor | QSFP28 (Digital Coherent Optics) |
| Application | DCI, Metro DWDM, Long-haul, Backhaul Networks |
| Connector | Duplex LC |
| Fiber Type | OS2 Single-Mode Fiber |
| Data Rate | Up to 128 Gb/s (Line Rate) |
| Client Interface | 100GE / OTU4 |
| Modulation | DP-QPSK / DQPSK |
| Wavelength | Full C-Band Tunable (ITU-T G.694.1) |
| Transmission Distance | Up to 120 km (Unamplified) |
| Power Supply | +3.3 V |
| Power Consumption | 13 W (ST) / 15 W (IT) |
| Operating Temperature | ST: −5°C to +70°C / IT: −40°C to +85°C |
| Housing | Metal enclosure (Low EMI) |
| Hot Plug | Supported |
| Compliance | RoHS-6 |
| Laser Safety | Class I (FDA/CDRH, IEC 60825) |
Transmitter Optical Specifications
| Parameter | Min | Max | Unit |
|---|---|---|---|
| Output Power | -8 | -5 | dBm |
| SMSR | 40 | — | dB |
| Tx Power Accuracy | -2 | +2 | dB |
| Tx Power Imbalance | — | 2 | dB |
| Tx XY Skew | — | 3 | ps |
| Tx IQ Imbalance | — | 1 | dB |
| Tx Quadrature Error | -5 | +5 | ° |
| Tx IQ Skew | — | 2 | ps |
| EVM Mask Ratio | — | 18 | % |
| In-band OSNR | 40 | — | dB/0.1nm |
| Tx Reflectance | — | -22 | dB |
Receiver Optical Specifications
| Parameter | Min | Max | Unit |
|---|---|---|---|
| Input Power Range | -40 | +5 | dBm |
| Sensitivity | — | -32 | dBm |
| Chromatic Dispersion | — | 10 | ns/nm |
| PMD Tolerance | — | 16 | ps |
| PDL Penalty | — | 1 | dB |
| SOP Tracking | — | 100 | kHz |
| Rx Reflectance | — | -22 | dB |
| LOS Assert | -40 | — | dBm |
| LOS De-assert | — | -32 | dBm |
| LOS Hysteresis | — | 5 | dB |
| OSNR (Metro) | 16.5 | — | dB/0.1nm |
| OSNR (Long-haul) | 15 | — | dB/0.1nm |
Ask a question
Questions & answers
0 question(s)No questions yet. Be the first to ask!
0.0
5★
0
4★
0
3★
0
2★
0
1★
0
Write a review
Sign in to reviewCustomer reviews
No reviews yet. Be the first to review this product.
No videos for this product yet
Once videos are added, you’ll see them here as a gallery.
Related Products
800G OSFP224 SMF OS2 LC Duplex 1310nm
