Sendun Fusion Splicer
SD-9 (Core-to-Core Alignment) • SD-6A (Core Alignment) • High-Speed Fusion Splicer
The Sendun SD-9 and Sendun SD-6A Fusion Splicers are professional optical fiber fusion splicing machines designed for FTTH deployment, ISP maintenance, backbone fiber installation, telecom projects, and data center applications. Featuring high-speed core alignment technology, a 4.3-inch touch screen, integrated Visual Fault Locator (VFL), Optical Power Meter (OPM), automatic ARC calibration, and long-lasting battery performance, these fusion splicers deliver fast, accurate, and reliable fiber splicing in demanding field environments.
With advanced imaging, low splice loss, rapid heating, and support for multiple fiber types, the SD-9 and SD-6A are ideal solutions for professional fiber optic technicians seeking precision and efficiency.
Key Features
Technical Specifications
| Parameter | Specification |
|---|---|
| Models | SD-9 (Core-to-Core Alignment), SD-6A (Core Alignment) |
| Applicable Fibers | SM (G.652 & G.657), MM (G.651), DS (G.653), NZDS (G.655) |
| Compatible Fiber / Cable | 0.25 – 3.0 mm Indoor Cable |
| Cladding Diameter | 80 – 150 μm |
| Cleave Length | 8 – 16 mm (0.125 – 1 mm coating) |
| Splice Modes | 41 Preset Modes, 100 User Storable Modes |
| Typical Splice Loss | SM: 0.02 dB • MM: 0.01 dB • DS: 0.04 dB • NZDS: 0.05 dB • G657: 0.03 dB |
| Return Loss | ≥ 60 dB |
| Lighting | Dual High-Power White LEDs |
| Splicing Time | 5 Seconds (FAST Mode) |
| Estimated Splice Loss | Supported |
| Protection Sleeve | 20 – 60 mm |
| Heating Modes | 20 / 30 / 40 / 50 / 60 mm Preset, 100 User Modes |
| Heating Time | 11 Seconds |
| Storage Capacity | 20,000 Splice Records & 200 Images |
| Tension Test | 2.0 N |
| Display | 4.3-inch Touch Screen LCD |
| Magnification | 380× (X / Y / XY View) |
| Fiber Holder | Multi-function Removable Clamp |
| Power Supply | AC 100–240V / DC 12–15V |
| Battery | 7200mAh Lithium Battery (Approx. 320 Splice & Heat Cycles) |
| Operation | Touch Screen & Physical Buttons |
| ARC Calibration | Automatic |
| Electrode Life | Up to 5,000 Arc Discharges |
| Communication Interface | USB 2.0 |
| Weight | 1.75 kg |
| Dimensions | 135.1 × 205.9 × 130.4 mm |
| Operating Conditions | -15°C to +50°C • 0–95% RH • Wind Speed ≤15 m/s |
| Storage Conditions | -40°C to +80°C • 0–95% RH |
| Built-in VFL | 15mW • Continuous & 2Hz Flashing Mode |
| Built-in Optical Power Meter | 850 / 1300 / 1310 / 1490 / 1550 / 1625nm • -50 to +26 dBm |
Applications
FTTH Installation • ISP Maintenance • Telecom Networks • Optical Backbone Projects • Data Centers • Enterprise Networks • Fiber Repair & Maintenance • Utility Fiber Networks • Government & Campus Networks
