Fusion splicer saluki

0.0

0 ratings

-4% Rs 287,500 .00

M.R.P.: ~~Rs 299,000.00~~

Exclusive of all taxes

Variation: 2000H

Download Datasheet Save

SKU: #1339 Category: Optical Fusion Splicer & accessories

Rs 287,500.00 -4%

M.R.P. ~~Rs 299,000.00~~

Excl. taxes

Min. Order	Unit Price
1 Piece	Rs 287,500.00

Trade Assurance Built-in order protection

In Stock

FREE Delivery on eligible orders

Deliver to

Select a city to check delivery

Supplier Info

D-TECH

Verified Supplier

4.8 / 5.0 Response Rate

7-Day Returns
if defective or damaged

Warranty
Seller warranty (if applicable)

Secure Payment
Multiple options available

Saluki Fusion Splicer

Category	Specification
Fiber Types	SMF (G.652), MMF (G.651), DSF (G.653), NZDSF (G.655), BIF (G.657)
Fiber Diameter	Cladding: 80–150μm, Coating: 100–3000μm
Cleave Length	5–16mm (<250μm), 10mm (0.25–3mm)
Splice Loss	SMF: 0.03dB, MMF: 0.02dB, DSF: 0.05dB, NZDSF: 0.05dB, BIF: 0.03dB
Return Loss	> 60dB
Splicing Time	7 sec (Quick Mode), 10 sec (Auto Mode)
Heating Time	15–18 sec (40mm / 60mm sleeve)
Battery Capacity	Approx. 400 splice & heat cycles
Fiber View	2 CMOS cameras, 240X (single axis), 160X (dual axis)
Tension Test	1.96 – 2.25N
Protection Sleeve	60mm, 40mm and more
Operation Mode	Manual / Auto
Splice Programs	Max 304 (18 preset, 286 editable)
Heating Programs	Max 104 (11 preset, 93 editable)
Data Storage	30,000 fusion records
Fiber Holder	3-in-1 (250μm, 900μm, 2–3mm cable, drop cable)
Auto Functions	Arc calibration, Motor calibration, Electrode stabilization, Self-test
User Training	Available
Display	4.3” Touch Screen Color LCD
Size	120 × 130 × 154 mm
Weight	1.95 kg (with battery), 1.65 kg (without)
Ports	USB 2.0, SD Card
Power Input	DC 10–15V / AC 100–240V
Battery	Li-ion 11.1V, 6800mAh
Operating Condition	Temp: -20~50°C, Humidity: 0–95%, Altitude: up to 6000m, Wind ≤15m/s
Electrode Life	5,000 arc discharges
