| Size & Weight | 156 × 135 × 149 mm, 1.7 kg (2.5 kg with battery) |
| Applicable Fibers | SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZ/NZ-DS (ITU-T G.655), BI (ITU-T G.657) |
| Fiber Count | Single to 12-core ribbon |
| Cladding Diameter | Single: 125 μm / 160 μm to 3 mm by fiber-holder system |
| Sheath Diameter | Ribbon: 125 μm / Ribbon fiber thickness 0.25–0.4 mm |
| Cleave Length | 9 mm – 9.5 mm |
| Splice Modes | 100 total splice modes |
| Typical Splice Time | 13 sec (SM FAST), 16 sec (SM AUTO) |
| Heating Modes | 20 heating modes |
| Typical Tube Heating Time | 18 sec (SM FAST) |
| Applicable Sleeve | 25–60 mm sleeves |
| Splice Image Capture | Max. 800 images |
| Splice Result Storage | Max. 10,000 records |
| Typical Splice Loss | SM: 0.05 dB, MM: 0.03 dB, DS: 0.08 dB, NZ/NZ-DS: 0.08 dB, BI: 0.05 dB |
| Return Loss | > 60 dB |
| Fiber View | Dual-axis CMOS camera with 4.3-inch high-brightness color LCD |
| Fiber Magnification | X / Y (32–100×), or simultaneous X+Y |
| Operating Conditions | Altitude: 0–3800 m; Temperature: –10°C to +50°C; Wind: 15 m/s; Humidity: 0–95% RH |
| Tension Test | 1.96N – 2.25N |
| Electrode Life | 2000 splices |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Battery | 8400 mAh high-capacity battery; >240 cycles (splicing + heating) |
| Terminal | USB 2.0 for PC connection |
| Other Features | Time-delay password security, Anti-theft ID electrode system |
| Optional | GPS location system |
