Category
|
Specification
|
|
Model
|
Comway
C10S V2
|
|
Type
|
Core
Alignment Fusion Splicer
|
|
Application
|
SM
(ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZ/NZDS (ITU-T G.655), BI
(ITU-T G.654), EB (ITU-T G.654)
|
|
Splice
Method
|
Core
alignment with 6 motors
|
|
Splice
Loss
|
0.02dB
(SM), 0.01dB (MM), 0.04dB (DS/NZDS)
|
|
Return
Loss
|
>60dB
|
|
Protection
Sleeve Length
|
10mm
- 60mm
|
|
Splicing
Time
|
~5
seconds (SM FAST mode)
|
|
Heating
Time
|
~8
seconds
|
|
Splice
Cycle per Battery Charge
|
>300
cycles
|
|
Magnification
|
750X
single-axis view
|
|
Display
|
High-resolution
LCD touchscreen, visible under sunlight
|
|
Shock
Resistance
|
Withstands
drop from 76cm on 5 sides
|
|
Waterproof
|
IP52
rated
|
|
Dustproof
|
IP5X
rated
|
|
Wind
Resistance
|
Up
to 15m/s
|
|
Operating
Temperature
|
-10°C
to +50°C
|
|
Storage
Temperature
|
-40°C
to +80°C
|
|
Humidity
|
0-95%
RH (non-condensing)
|
|
Power
Supply
|
AC
100-240V, 50/60Hz; DC 12V input
|
|
Battery
Capacity
|
7800mAh
lithium-ion, rechargeable
|
|
Charging
Time
|
~3
hours
|
|
Fiber
Cleaver
|
High-precision
fiber cleaver included
|
|
Stripping
|
Suitable
for 250μm and 900μm coated fibers
|
|
Auto
Fiber Identification
|
YES
|
|
Splice
Programs
|
Multiple
pre-installed and customizable programs
|
|
Remote
Locking
|
Anti-theft
protection with remote access
|
|
GPS
Function
|
Optional
GPS module available
|
|
Language
Support
|
Multiple
languages supported
|
|
Interface
|
USB
and HDMI for data transfer and software updates
|
