Advantages
1.
Soft rubber can cushion the strength
when falling.
2.
Multi-color appearance can meet a
variety of choices.
3.
Aluminum alloy body surface uses
sandblasting and anti-rust treatment, making it resistant to corrosion and
ensuring a high life expectancy.
4.
The four-column support structure
has good impact resistance. It is sturdy and not easily deformed. It also
features a rubber pad gap adjustment structure, making it easy to adjust and
maintain.
5.
The diameter of the shaft is
thickened from 3mm to 4mm, doubling its strength.
6.
The patented design ball groove
impact self-returning positioning mechanism allows automatic reset after
dropping and impacting.
7.
High-elastic rubber fleece and
double ruler 3-in-1 fixture help prevent fiber breakage.
8.
The special composition rubber
stainless steel pressure pads are resistant to oil, alcohol, and abrasion,
ensuring high stability over long periods.
9.
High-precision heat-treated
stainless steel slides ensure smooth and fluid cutting.
10. The automatic return design enhances cutting efficiency.
|
Specification
|
|
Details
|
|
|
Material and Surface Treatment
|
|
Aluminum, Soft Rubber
|
|
|
Cutter Specification
|
|
Single-core quartz fiber, Inner
bore Ø 4mm, External diameter Ø 22mm
|
|
|
Coated Diameter of Suitable Fiber
|
|
Ø 0.25 & 0.9, 125um
|
|
|
Clad Diameter of Suitable Fiber
|
|
Ø 0.25 & 0.9, 125um
|
|
|
Cleaving Fiber Length
|
|
9-16mm (Ø 0.25), 10-16mm (Ø 0.9)
|
|
|
External Appearance Size
|
|
60mm (W) × 57mm (D) × 46mm (H)
|
|
|
Weight
|
|
266g
|
|
|
Fiber Holder
|
|
3 in 1
|
|
|
Blade Hardness and Size
|
|
≥92.5HRa, 22 × 4 × 2mm
|
|
|
Cleaving Angle
|
|
≤0.8°
|
|
|
Blade Service Life
|
|
48000 times
|
|
|
Pressure Pad
|
|
Stainless Steel or Plastic
|
|
