Fusion Splicer Sumitomo
-3%
Rs
370,000
.00
M.R.P.: Rs 380,000.00
Exclusive of all taxes
.jpg)
Rs 370,000.00
-3%
M.R.P. Rs 380,000.00
Excl. taxes
| Min. Order | Unit Price |
|---|---|
| 1 Piece | Rs 370,000.00 |
Trade Assurance
Built-in order protection
In Stock
FREE Delivery on eligible orders
Select a city to check delivery
Supplier Info
D-TECH
Verified Supplier
4.8 / 5.0 Response Rate
7-Day Returns
if defective or damaged
if defective or damaged
Warranty
Seller warranty (if applicable)
Seller warranty (if applicable)
Secure Payment
Multiple options available
Multiple options available
Fusion Splicer Specifications
The TYPE-81C fusion splicer is designed for precise fiber splicing with low splice loss, fast operation, and reliable field performance. It supports multiple fiber types and is suitable for telecom, FTTH, and backbone network applications.
Optical Fiber
| Item | Specification |
|---|---|
| Material | Silica glass |
| Fiber Type | SM (G.652), MM (G.651), DSF (G.653), NZDSF (G.655), BIF (G.657), EDF |
| Fiber Diameter | Cladding: 80–150 μm, Coating: 100–1000 μm |
| Cleave Length | 5–16 mm |
Performance
| Item | Specification |
|---|---|
| Splice Loss | SM: 0.01 dB, MM: 0.01 dB, DSF/NZDSF: 0.03 dB |
| Return Loss | ≥ 60 dB |
| Splice Time | 6 sec (Quick), 7 sec (Std), 8 sec (Auto) |
| Heating Time | 14 sec (60mm sleeve) |
| Battery Cycles | Approx. 230 splice & heat cycles |
| Magnification | 700× zoom (single), 88× dual axis |
Programs
| Item | Specification |
|---|---|
| Splice Programs | Max. 300 (74 preset, 226 user) |
| Heating Programs | Max. 100 (24 preset, 76 user) |
Functions
| Item | Specification |
|---|---|
| Data Storage | 10,000 splice data (internal), up to 50,200 (SD card) |
| Attenuation Splicing | 0.1–15 dB (0.1 dB step) |
| Automatic Calibration | Environmental auto compensation |
| Fiber Identification | SM / MM / DSF / NZDSF / BIF |
| Remaining Cycles Display | Available (Battery mode) |
Size & Weight
| Item | Specification |
|---|---|
| Dimensions | 120 × 154 × 130 mm |
| Weight | 1.8 kg (without battery), up to 2.1 kg with battery |
Power
| Item | Specification |
|---|---|
| AC Input | AC 100–240V |
| DC Input | DC 10–15V |
| Battery | Li-ion 11.1V (2300mAh / 4600mAh) |
Environment
| Item | Specification |
|---|---|
| Operating | -10°C to +50°C, 0–95% RH |
| Storage | -40°C to +80°C |
Additional Information
| Item | Specification |
|---|---|
| Electrode Life | 6000 arcs |
