Fusion Splicer Sumitomo
81C
Variant Specifications
Technology:
Warranty:
Product size:
Weight:
Payment Facility:
More Details:
Delivery Lead Time:
Origin:
.jpg){kind=small}
Z1C
Z2C
4% OFF
Rs 467,398.75
List: Rs 486,094.70
Fusion Splicer Specifications (TYPE-81C)
The TYPE-81C fusion splicer is designed for precise fiber splicing with low splice loss, fast operation, and reliable field performance. It supports multiple fiber types and is suitable for telecom, FTTH, and backbone network applications.
Optical Fiber
| Item | Specification |
|---|---|
| Material | Silica glass |
| Fiber Type | SM (G.652), MM (G.651), DSF (G.653), NZDSF (G.655), BIF (G.657), EDF |
| Fiber Diameter | Cladding: 80–150 μm, Coating: 100–1000 μm |
| Cleave Length | 5–16 mm |
Performance
| Item | Specification |
|---|---|
| Splice Loss | SM: 0.01 dB, MM: 0.01 dB, DSF/NZDSF: 0.03 dB |
| Return Loss | ≥ 60 dB |
| Splice Time | 6 sec (Quick), 7 sec (Std), 8 sec (Auto) |
| Heating Time | 14 sec (60mm sleeve) |
| Battery Cycles | Approx. 230 splice & heat cycles |
| Magnification | 700× zoom (single), 88× dual axis |
Programs
| Item | Specification |
|---|---|
| Splice Programs | Max. 300 (74 preset, 226 user) |
| Heating Programs | Max. 100 (24 preset, 76 user) |
Functions
| Item | Specification |
|---|---|
| Data Storage | 10,000 splice data (internal), up to 50,200 (SD card) |
| Attenuation Splicing | 0.1–15 dB (0.1 dB step) |
| Automatic Calibration | Environmental auto compensation |
| Fiber Identification | SM / MM / DSF / NZDSF / BIF |
| Remaining Cycles Display | Available (Battery mode) |
Size & Weight
| Item | Specification |
|---|---|
| Dimensions | 120 × 154 × 130 mm |
| Weight | 1.8 kg (without battery), up to 2.1 kg with battery |
Power
| Item | Specification |
|---|---|
| AC Input | AC 100–240V |
| DC Input | DC 10–15V |
| Battery | Li-ion 11.1V (2300mAh / 4600mAh) |
Environment
| Item | Specification |
|---|---|
| Operating | -10°C to +50°C, 0–95% RH |
| Storage | -40°C to +80°C |
Additional Information
| Item | Specification |
|---|---|
| Electrode Life | 6000 arcs |
Ask a question
Questions & answers
0 question(s)No questions yet. Be the first to ask!
0.0
5★
0
4★
0
3★
0
2★
0
1★
0
Write a review
Sign in to reviewCustomer reviews
No reviews yet. Be the first to review this product.
Product Videos
