ADSS Suspension Clamp Span 100M
Discover our latest products and services
Available Variants
Product Info
- Unit: pc(1)
- Product ID: 686
Request a Quote
Contact us for pricing details.
Suspensions set for
100m span
Description:
The ADSS suspension clamp is used to connect the ADSS cables on the straight
pole/towers. They feature in sample structures, easy installation and lower
cost.
1. Configuration:
|
S.NO |
Description |
Code |
Material |
Qty |
Weight(kg) |
|
1 |
U clevis |
U-5 |
Forged steel |
1 |
0.3 |
|
2 |
Housing |
Aluminum alloy,length:1 00mm |
1 |
0.4 |
|
|
3 |
Synthetic rubber length:120m m |
1 |
0.15 |
||
|
Total weight(kg) |
0.85 |
||||
Type 1:
1- Anchor shackle:
forged steel 2- Housing: aluminum alloy
3- Rubber insert: synthetic rubber 4- Bolt, nut, cotter pin
Type 2:
1- Stainless steel band
(1.2m)
2- Stainless steel base: 1pcs
3- Rubber insert : synthetic rubber
4- Housing: aluminum alloy
5- Bolt, nut, washer, spring washer: 1set
2. Features:
Simple structures,
easy installation, and lower cost.
Applications: Poles/towers with span of less than 100m, and
line angle of less
than 15°
4. Technical Data:
RTS: greater than 20kN
recommended span length: 100m
|
SN |
Cable Diameter (mm) |
Armor Rods (mm) |
Anchor Shackle |
|
1 |
9.0-12 |
0 |
U-5 |
|
2 |
12-14 |
0 |
U-5 |
|
3 |
14-16 |
0 |
U-5 |
|
4 |
16-18 |
0 |
U-5 |
Additional Specifications
| Base Unit | pc(1) |
|---|---|
| Category | Optical Fiber Cable and Accessories |
| SKU | |
| Product Code | 34 |
| Trackable | Yes |
| Taxable | Yes |
