DWDM MUX AND DEMUX (Red21-28) (Blue 51-58) 1U RACK 8CH WITH 2 LGX BOX BIDI SINGLE FIBER
| Min. Order | Unit Price |
|---|---|
| 1 Set(1) | Rs 104,198.40 |
if defective or damaged
Seller warranty (if applicable)
Multiple options available
8 Channel DWDM MUX / DEMUX (BiDi) – Red 21–28 & Blue 51–58 (1U Rack with 2 LGX Modules)
Passive DWDM Multiplexer & Demultiplexer • 1U Rack Mount • Single Fiber Transmission • ITU-T DWDM
The 8 Channel DWDM MUX / DEMUX (BiDi) is a high-performance Dense Wavelength Division Multiplexing (DWDM) system designed to combine and separate multiple optical wavelengths over a single optical fiber using bidirectional (BiDi) transmission. It supports 8 DWDM channels distributed across two wavelength groups: Red Channels 21–28 and Blue Channels 51–58, maximizing fiber utilization while reducing infrastructure costs.
Housed in a standard 1U 19-inch rack-mount chassis, the unit includes 2 LGX fiber modules (boxes) for organized fiber management and easy installation. As a fully passive optical device, it requires no external power, offering excellent reliability, minimal maintenance, and long-term stable performance for telecom operators, ISPs, enterprise backbone networks, and data centers.
Key Features
Technical Specifications
| Category | Specification |
|---|---|
| Product Type | DWDM MUX / DEMUX (BiDi) |
| DWDM Channels | 8 Channel |
| Channel Group | Red 21–28 & Blue 51–58 |
| Transmission Mode | Single Fiber BiDi |
| Technology | Dense Wavelength Division Multiplexing (DWDM) |
| Rack Size | 1U, 19-inch Rack Mount |
| Fiber Modules | 2 × LGX Fiber Modules |
| Power Requirement | Passive Device (No Power Required) |
| Installation | Standard 19-inch Rack |
| Application | Metro Networks, ISP, Telecom, Enterprise Backbone, Data Center |
Channel Configuration
| Channel Group | ITU-T DWDM Channels | Transmission |
|---|---|---|
| Red Band | CH21 – CH28 | BiDi |
| Blue Band | CH51 – CH58 | BiDi |
Applications
Advantages of DWDM Technology
- Increase fiber transmission capacity without deploying additional fiber.
- Supports simultaneous transmission of multiple independent optical channels.
- Passive architecture offers excellent reliability with zero power consumption.
- Ideal for high-bandwidth metro, telecom, ISP, and data center backbone applications.
- Scalable solution for future network expansion while minimizing infrastructure costs.
