1xX PLC Splitter
Product Overview
The 1*X PLC Splitter is a high-quality optical device designed to split one optical input signal into 16 output fibers with low loss and stable performance. It is widely used in FTTH (Fiber to the Home), PON (Passive Optical Networks), broadband distribution, and telecom fiber networks. This version comes without connectors, allowing flexible customized installation based on project requirements.
Applications
| Application Areas |
|---|
| FTTH (Fiber to the Home) networks |
| PON (Passive Optical Networks) |
| Large-scale broadband networks |
| Data centers and telecommunications |
| Fiber optic network distribution |
Technical Specifications
| Specification | Details |
|---|---|
| Splitter Type | 1xX PLC (Planar Lightwave Circuit) Splitter |
| Wavelength Range | 1260 nm to 1650 nm |
| Insertion Loss | ≤ 18 dB (Max) |
| Return Loss | ≥ 50 dB (Typical) |
| Fiber Type | SMF (Single-Mode Fiber) |
| Split Ratio | 1 Input to 16 Outputs |
| Fiber Length | Customizable (typically 1.5 m to 3 m) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L × W × H) | 60 mm × 25 mm × 7 mm |
| Fiber Connector Type | None (Raw Fiber Ends for Customization) |
| Uniformity | ≤ 1.5 dB |
| Packaging | Plastic Tube (for Fiber Protection) |
| Environmental Rating | RoHS Compliant, CE Certified |
Product Features
| Feature | Benefit |
|---|---|
| Compact Design | Ideal for large-scale network setups with efficient space usage |
| Low Insertion Loss | Maintains signal integrity over long-distance transmission |
| High Reliability | Stable performance in demanding telecom and broadband environments |
| Versatile Usage | Suitable for FTTH, telecommunications, broadband, and fiber distribution systems |
