Fiber Optic Splitter Without  Connector - Splitter W/C 1*2
Selected variant

Fiber Optic Splitter Without Connector

Splitter W/C 1*2
Variant Specifications
Warranty:
Weight:
Country of Origin:
Lead Time:
More Details:
Package:
1% OFF Rs 224.4300
List: Rs 226.9900

1x2 PLC Splitter (Without Connector)

Product Overview

The 1x2 PLC Splitter without connectors is a high-performance passive optical device designed to split one input fiber into two output fibers with uniform signal distribution. It is widely used in FTTH and PON networks, ensuring stable and efficient performance with minimal signal loss. Built using advanced PLC technology, it supports a wide wavelength range and reliable operation in demanding environments.

Key Features

Feature Details
Split Ratio 1 Input to 2 Outputs (1x2)
Wide Wavelength Range 1260 nm to 1650 nm (GPON / EPON compatible)
Low Insertion Loss Minimal signal degradation with uniform output
Compact Design Lightweight and easy to install in fiber enclosures
Environmental Stability Operates reliably from -40°C to +85°C
Connector Type No connectors (bare fiber for custom splicing)

Technical Specifications

Parameter Value
Type PLC Splitter (1x2)
Configuration 1 Input, 2 Outputs
Fiber Type Single Mode (G.657A / G.652D)
Wavelength Range 1260 – 1650 nm
Insertion Loss ≤ 3.8 dB
Return Loss ≥ 55 dB
PDL ≤ 0.2 dB
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Dimensions Compact & lightweight design

Applications

Application Areas
FTTH (Fiber to the Home) Networks
PON (GPON, EPON, BPON)
CATV Systems
Fiber Testing & Measurement
LAN / WAN Fiber Networks
