Product Description
The HSGQ-5528 is
a high-performance Layer-3 managed Ethernet switch designed
for enterprise networks, ISPs, hotels, campuses, data centers, and
smart buildings.
It features 24 Gigabit Ethernet ports with 4 × 10G
SFP+ uplinks, offering excellent switching capacity, advanced L3 routing,
and full security features.
Hardware Specifications
➤ Model: HSGQ-5528
➤ Downlink Ports: 24
× 10/100/1000 Mbps RJ45
➤ Uplink Ports: 4
× 10G SFP+
➤ Switching
Capacity: 128 Gbps
➤ Packet
Forwarding Rate: 95.2 Mpps
➤ MAC Address
Table: 32K
➤ Jumbo Frame: 9
KB
➤ Buffer Memory: 2
MB
➤ Flash Memory: 256
MB
➤ SDRAM: 512
MB
➤ Power Supply: AC
100–240V, 50/60Hz
➤ Power
Consumption: ≤ 30W
➤ Dimensions (W ×
D × H): 440 × 220 × 44 mm
➤ Installation: Desktop
/ Rack-mount
➤ Cooling: Intelligent
fan cooling
➤ Operating
Temperature: 0°C to 45°C
➤ Storage
Temperature: −40°C to 85°C
Layer-2 Features
➤ VLAN (Port-based &
IEEE 802.1Q)
➤ QinQ / Port VLAN
➤ Link Aggregation (LACP)
➤ Spanning Tree Protocol:
STP / RSTP / MSTP
➤ Port Mirroring
➤ IGMP Snooping (V1 / V2
/ V3)
➤ Jumbo Frame Support
➤ Loopback Detection
➤ Flow Control (IEEE
802.3x)
Layer-3 Features
➤ Static Routing
➤ RIP / RIPng
➤ OSPF / OSPFv3
➤ VRRP
➤ DHCP Server, DHCP Relay
& DHCP Snooping
➤ ARP Management
➤ ICMP Control
Security Features
➤ ACL (IP / MAC /
Port-based)
➤ Port Security
➤ Storm Control
➤ DHCP Snooping
➤ IP Source Guard
➤ ARP Inspection
➤ IEEE 802.1X
Authentication
➤ Secure Management via
SSH & HTTPS
Management & Monitoring
➤ Web GUI Management
➤ CLI Management (Console
/ SSH / Telnet)
➤ SNMP v1 / v2c / v3
➤ RMON
➤ Syslog
➤ NTP Time
Synchronization
➤ Configuration Backup
& Restore
➤ Firmware Upgrade via
Web or CLI
Download (HSGQ 5528 Series) : Data sheet in PDF File
