L3 Managed Industrial Switch HSGQ 5528 Series
Variant Specifications
HSGQ-5528 Layer-3 Managed Ethernet Switch
The HSGQ-5528 Layer-3 Managed Ethernet Switch is a high-performance enterprise switch designed for data centers, ISPs, campus networks, hotels, and enterprise deployments. Featuring 24 Gigabit RJ45 ports and 4 × 10G SFP+ uplink ports, it delivers reliable high-speed connectivity, advanced Layer-3 routing, and enterprise-class network security.
With a 128 Gbps switching capacity, 95.2 Mpps forwarding rate, support for Static Routing, RIP, OSPF, VLAN, ACL, SNMP, SSH, and intelligent fan cooling, the HSGQ-5528 provides a scalable and secure networking solution for modern business infrastructures.
Quick Specifications
Key Features
- 24 × 10/100/1000 Mbps Gigabit RJ45 ports
- 4 × 10G SFP+ high-speed uplink ports
- Layer-3 routing with Static Routing, RIP & OSPF
- 128 Gbps switching capacity
- 95.2 Mpps packet forwarding performance
- 32K MAC address table
- IEEE 802.1Q VLAN & QinQ support
- LACP Link Aggregation
- STP / RSTP / MSTP
- ACL, Port Security & ARP Protection
- Web GUI, CLI, SNMP, SSH & Telnet management
- Intelligent fan cooling with low power consumption
Applications
Enterprise Networks
High-performance switching for corporate offices and enterprise LAN infrastructure.
ISP Networks
Ideal for broadband aggregation, fiber backbone, and telecom deployments.
Hotels & Campuses
Reliable connectivity for hotels, universities, hospitals, and smart buildings.
Data Centers
Suitable for aggregation layer, server connectivity, and high-speed backbone switching.
Technical Specifications
| Category | Specification |
|---|---|
| Model | HSGQ-5528 |
| Product Type | Layer-3 Managed Ethernet Switch |
| Downlink Ports | 24 × 10/100/1000 Mbps RJ45 |
| Uplink Ports | 4 × 10G SFP+ |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| MAC Address Table | 32K |
| Jumbo Frame | 9 KB |
| Memory | Buffer: 2 MB Flash: 256 MB SDRAM: 512 MB |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption | ≤ 30W |
| Dimensions | 440 × 220 × 44 mm |
| Installation | Desktop / Rack Mount |
| Cooling | Intelligent Fan Cooling |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 85°C |
Advanced Features
| Feature | Details |
|---|---|
| VLAN | Port-based VLAN, IEEE 802.1Q, QinQ |
| Link Aggregation | LACP |
| Spanning Tree | STP / RSTP / MSTP |
| Routing | Static Routing, RIP, OSPF |
| Security | ACL, Port Security, Storm Control, ARP Protection |
| Management | Web GUI, CLI, SNMP, Telnet, SSH |
| Monitoring | SNMP v1/v2c/v3, RMON, Syslog |
Installation Recommendation
Install the HSGQ-5528 in a standard 19-inch equipment rack with adequate airflow for efficient cooling. Use the 10G SFP+ uplink ports for backbone connectivity and configure VLANs, Link Aggregation (LACP), ACLs, and Layer-3 routing to optimize network performance, security, and scalability. Regularly monitor switch status using SNMP, Syslog, or the Web GUI to maintain reliable network operation.
