GPON OLT SFP Module
B+ • C++ • C+++ • C++++ • GPON OLT Optical Transceiver
The GPON OLT SFP Module is designed for GPON access networks and supports high-performance optical transmission between OLT and ONU devices. These modules utilize 1490nm transmission and 1310nm reception wavelengths with an integrated WDM filter, providing reliable connectivity for FTTH, ISP, telecom, and enterprise GPON deployments.
Available in B+, C++, C+++, and C++++ optical budget classes, these modules support long-distance fiber transmission and high split-ratio GPON network architectures.
GPON Speed
1.25G
Wavelength
1490/1310
Form Factor
SFP
Connector
SC
Key Features
✔ GPON Access Network Support
✔ 1490nm DFB Continuous Mode Transmitter
✔ 1310nm Burst Mode APD Receiver
✔ Integrated WDM Filter
✔ Digital Diagnostic Monitoring (DDM)
✔ SFF-8472 Compatible
✔ Hot-Pluggable SFP Design
✔ RoHS Compliant
Product Specifications
| Model | Package | Data Rate | Wavelength | Laser | Tx Power | Interface |
|---|---|---|---|---|---|---|
| GPON OLT B+ | SFP | 1.25G / 1.25G | Tx1490 / Rx1310 | DFB / APD | 3 ~ 5 dBm | SC |
| GPON OLT C++ | SFP | 1.25G / 1.25G | Tx1490 / Rx1310 | DFB / APD | 5 ~ 7 dBm | SC |
| GPON OLT C+++ | SFP | 1.25G / 1.25G | Tx1490 / Rx1310 | DFB / APD | 7 ~ 10 dBm | SC |
| GPON OLT C++++ | SFP | 1.25G / 1.25G | Tx1490 / Rx1310 | DFB / APD | 9 ~ 10 dBm | SC |
Receiver Sensitivity
| Module Type | Receiver Sensitivity |
|---|---|
| GPON OLT B+ | ≤ -30 dBm |
| GPON OLT C++ | ≤ -32 dBm |
| GPON OLT C+++ | ≤ -32 dBm |
| GPON OLT C++++ | ≤ -32 dBm |
Absolute Maximum Ratings
| Parameter | Symbol | Min | Max | Unit |
|---|---|---|---|---|
| Storage Temperature | Ts | -40 | +85 | °C |
| Operating Temperature | Top | 0 | +70 | °C |
| Supply Voltage | Vcc | -0.5 | +3.6 | V |
| Supply Current | Icc | - | 400 | mA |
Recommended Operating Conditions
| Parameter | Symbol | Min | Max | Unit |
|---|---|---|---|---|
| Operating Temperature | Top | 0 | +70 | °C |
| Supply Voltage | Vcc | 3.1 | 3.5 | V |
