1% OFF
Rs 85.00
List: Rs 86.00
GYXTC8Y Aerial Fig-8 Single Mode Fiber Cable - 6 Core
The GYXTC8Y Aerial Fig-8 Fiber Optic Cable is designed for outdoor aerial installation with integrated messenger wire support. It uses Single Mode G.652D optical fiber, PE sheath, loose tube protection, and steel wire armor for reliable performance in telecom, ISP, FTTH backbone, and long-distance fiber networks.
Cable Structure & Parameters
| Item | Unit | Details |
|---|---|---|
| Optical Fiber Type | — | Single Mode G.652D |
| Loose Tube Material | — | PBT |
| Loose Tube Diameter | mm | 3.0 |
| Armor Material | — | Steel wires covered with PE |
| Armor Diameter | mm | 12 × 0.6 mm steel wires with 1.0 mm PE |
| Sheath Material | — | PE |
| Sheath Diameter | mm | 8.2 ± 0.3 |
| Messenger Material | — | Stranded steel wires |
| Messenger Diameter | mm | 7 × 1.2 mm, total 3.6 mm |
| Tensile Strength | N | 1000 / 3000 |
| Crush Resistance | N / 100mm | 300 / 1000 |
Fiber Properties – ITU-T G.652D
| Item | Specification |
|---|---|
| Fiber Type | Single Mode |
| Fiber Material | Doped Silica |
| Attenuation @1310nm | ≤ 0.36 dB/km |
| Attenuation @1383nm | ≤ 0.32 dB/km |
| Attenuation @1550nm | ≤ 0.22 dB/km |
| Attenuation @1625nm | ≤ 0.30 dB/km |
General Optical & Mechanical Properties
| Item | Specification |
|---|---|
| Point Discontinuity | ≤ 0.05 dB |
| Cut-off Wavelength | ≤ 1260 nm |
| Zero Dispersion Wavelength | 1300 ~ 1324 nm |
| Zero Dispersion Slope | ≤ 0.093 ps/(nm²·km) |
| Chromatic Dispersion 1288 ~ 1339nm | ≤ 3.5 ps/(nm·km) |
| Chromatic Dispersion 1271 ~ 1360nm | ≤ 5.3 ps/(nm·km) |
| Chromatic Dispersion @1550nm | ≤ 18 ps/(nm·km) |
| Chromatic Dispersion @1625nm | ≤ 22 ps/(nm·km) |
| PMD | ≤ 0.2 ps/√km |
| Mode Field Diameter @1310nm | 9.2 ± 0.4 µm |
| Cladding Diameter | 125.0 ± 0.7 µm |
| Primary Coating Diameter | 245 ± 10 µm |
| Proof Test Level | 100 kpsi, approx. 0.69 GPa, 1% |
| Temperature Dependence | ≤ 0.1 dB/km from 0°C to +70°C |
Note: Sheath thickness tolerance is ±0.2 mm and outer diameter tolerance is ±0.3 mm.
Download: GYXTC8Y Aerial Fig-8 Fiber Cable datasheet available in PDF file.
