Product Description
HSGQ-F881 is
a Pof ceiling-mounted optical AP in FTTH solution. HSGQ-F881 provides 1'GE LAN
port, 12.5GE PD port and AX3000 WiFi, high-speed access, downlink 2.5Gbps,
uplink 1.25Gbps, supports plug-and-play, OMCI and TR009 remote maintenance
functions: supports optical-electrical hybrid cable access, no power adapter
required.
- Easy Installation: Directly installed on the ceiling, no additional power cord is required, saving wiring time and cost.
- Simple Appearance: Beautiful design, can be well integrated into the indoor environment.
- Wide Coverage: Generally equipped with high-gain antennas, wide signal coverage, can effectively solve the problem of signal dead spots.
- Easy Management: Most PoE ceiling APs support centralized management, which is convenient for configuration and maintenance.
- Application Scenario: Suitable for hotels, shopping malls, office buildings, schools and other places.
Key Feature
·
Adopting
point-to-multipoint network topology, effectively collecting and converging the
scattered Ethernet services of users, and providing standard RJ45 Fast Ethernet
interface on the user side
·
Dynamic bandwidth
allocation mechanism enables all users to share bandwidth more reasonably,
achieve reliable quality of service (QoS), and ensure the service quality of
different services in the same network
·
Support IGMP
multicast to effectively utilize broadband
·
Support multicast
VLAN
·
Provides remote
management via OLT and supports local console management
·
Support line
loopback detection function of user-side Ethernet interface
·
Support IEEE
802.10 VLAN protocol
·
Support broadcast
storm suppression
·
Support
IEEE802.3x flow control (fall duplex)
·
Support IEEE
802.1p. Cos protocol
·
Support WR and SP
queue scheduling algorithms
·
Support port
speed limit
·
Support-10°C-50°C
working environment
·
Supports IPv4 and
IPv6
·
Support cloud
management
·
Support PoF, support
PD
Technical Parameter
| Item | HSGQ-F881 |
| User Interface | 1*GE RJ45 |
| 1*2.5GE RJ45 PD |
| 2.4 GHz: 574Mbps, 5.8GHz: 2402Mbps |
| PON | GPON and EPON mode self-adaptation Interface mode: Optical-electric composite cable |
GPON: upstream 1.25Gbps /downstream 2.5Gbps Transmit optical power: 0~4dBm Optical Power: -7dBm~-28dBm |
EPON: upstream 1.25Gbps /downstream 1.25Gbps Transmit optical power: 0~4dBm Optical Power: -7dBm~-27dBm |
PoF Input voltage: 48V-57VPoF Transmission distance: 300m |
| Ethernet | 1*10/100/1000/2500M self-adaption |
| Transmission distance:100m |
| Size | 188mm x 180mm x 43mm |
| Environment | Operating temperature: -10°C~50°C |
| Operating humidity: 0%~85% (non-condensing) |
| Storage temperature: -40°C~80°C |
| Storage temperature: 5%~95% (non-condensing) |
| Power Supply | PoF: 48V-52V, 0.25A |
| DC: 12V/ 1.5A |
| Power Consumption | <12W |
WiFi6 AX3000
Ordering Information
Download HSGQ-F881 : Data sheet in PDF File
