Media Converter Overview:
The DK-MC1035 series media converter, Single Fiber 10/100/1000 20 KM, adopts a store and forward, no fan, low power consumption design with the advantages of convenient use, small size, and simple maintenance. Product design-20°C ~ +70°C wide range of operating temperature, stable and reliable performance, can be widely used in a variety of broadband data transmission fields.
Experience enhanced network management capabilities with features like broadcast filtering, address auto-learning, automatic updates, and store-and-forward operation, ensuring seamless data transmission with minimal latency.
With a 512KB cache and a MAC address table of 4KB, our converter delivers lightning-fast data processing while supporting a wide range of Ethernet standards, including 10Base-Tx to 10Base-Fx, 100Base-Tx to 100Base-Fx, and 1000Base-Tx to 1000Base-Fx fiber media conversion.
Compliant with IEEE standards such as 802.3, 802.3U, 802.1X, 802.3Z/AB, and 802.1d, our converter ensures compatibility and interoperability across diverse network environments.
Product parameter for Media Converter Single Fiber 10/100/1000 20 KM:
| Parameter | Details |
|---|
| Provider Mode | Ports |
| Fixed Port | 1 * 1000Base-X, 1 * 10/100/1000Base-T |
| Power Interface | DC Port |
| LED Indicators | PWR, Link/ACT LED |
| Cable Type & Transmission Distance | Twisted-pair: 0-100m (CAT5e, CAT6) |
| | Monomode Optical Fiber: 3KM/20KM/40KM/60KM/80KM/100KM/120KM |
| Electrical Specifications | |
| Input Voltage | DC 5V |
| Total Power Consumption | Total Power: < 4W |
| Environment | |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -20°C ~ +70°C |
| Relative Humidity | 5% ~ 95% non-condensing |
| Thermal Methods | Fanless design, natural heat dissipation |
| MTBF | 100,000 hours |
| Mechanical Dimensions | |
| Product Size | 93 x 71 x 27mm |
| Installation Method | Desktop |
| Weight | 0.17KG * 2 |
| Certification | |
| Certification | CE/FCC/RoHS |
| Accessories | |
| Accessories | Device, manual, power adapter (EU/US/UK/AU plug optional) |
