Experience cutting-edge Wi-Fi 6 technology with our AC1200 Full Router, JIR-AC666R2, offering faster speeds, expanded capacity, and minimized network congestion.
With next-generation speeds of up to 1.5 Gbps, our dual-band router delivers lightning-fast performance (1201 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band).
Empower your network to handle more devices effortlessly, thanks to Wi-Fi 6 technology's innovative OFDMA and MU-MIMO features, reducing latency and enhancing connectivity.
Powered by a robust 1.5 GHz tri-core processor, our router ensures seamless communication between your devices, eliminating buffering and ensuring smooth operation.
Enjoy unparalleled Wi-Fi coverage with the AC1200 Full Router JIR-AC666R2, utilizing beamforming technology and four antennas to focus signal strength precisely where you need it.
High Master Frequency: Processor operating main frequency up to 1.0 GHz, 1600 DMIPs, high specification, high power coverage | |||
QOS Intelligent Bandwidth: It can reasonably allocate and download bandwidth resources according to the needs of different users | |||
Multi-level security: support IP filtering, MAC filtering, SSID hiding, advanced encryption and other multi-level security precautions | |||
2T2R technology: signal dual channel transmission, dual channel reception | |||
WIFI-6 AC1200 Full Router JIR-AC666R2 |
Chipset | RTL8197FH-VG4+RTL8812FR+RTL8367RB-VC |
FLASH | 8MB |
DDR2 | 64MB |
Wireless rate | 2.4 GHz:300Mbps&2*2 |
5GHz:867Mbps&2*2 | |
Antenna | 4*5 dBi External antenna |
Interface | 1* GE WAN+3* GE LAN |
Button | 1* RESET+1* WPS |
Indicator | POWER WAN 2.4G 5G WPS |
Wi-Fi Agreement | IEEE 802.11b/g/n/ac support |
MIMO modalities | MU-MIMO |
Work model | Routing mode, AP mode, and relay mode |
Management approach | Chinese WEB Remote Management |
State | System state, interface state, and routing table |
Wireless Configuration | Wi-Fi Basic Parameter Configuration / Blacklist |
Network settings | Working mode: LAN/WAN address setting |
System | System properties/password modification/backup upgrade/restart |
Setup Wizard | Quick Configuration Wizard |
MTBF | >20000 H |
power consumption | ≤9 W |
Working temperature | 0℃~40℃ |
Storage temperature | -40℃~70℃ |
Working humidity | 10%~95%, no condensation |
Storage humidity | 5%~95%, no condensation |
Power adapter | DC 12V/1A |
