Product Overview of WIFI-6 AC1200 Full Router JIR-AC666R2:
Experience cutting-edge Wi-Fi 6 technology with our AC1200 Full Router, JIR-AC666R2, offering faster speeds, expanded capacity, and minimized network congestion.
With next-generation speeds of up to 1.5 Gbps, our dual-band router delivers lightning-fast performance (1201 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band).
Empower your network to handle more devices effortlessly, thanks to Wi-Fi 6 technology's innovative OFDMA and MU-MIMO features, reducing latency and enhancing connectivity.
Powered by a robust 1.5 GHz tri-core processor, our router ensures seamless communication between your devices, eliminating buffering and ensuring smooth operation.
Enjoy unparalleled Wi-Fi coverage with the AC1200 Full Router JIR-AC666R2, utilizing beamforming technology and four antennas to focus signal strength precisely where you need it.
Product Description OF WIFI-6 AC1200 Full Router JIR-AC666R2:
Product Specification:
| High Master Frequency: Processor operating main frequency up to 1.0 GHz, 1600 DMIPs, high specification, high power coverage |
| QOS Intelligent Bandwidth: It can reasonably allocate and download bandwidth resources according to the needs of different users |
| Multi-level security: support IP filtering, MAC filtering, SSID hiding, advanced encryption and other multi-level security precautions |
| 2T2R technology: signal dual channel transmission, dual channel reception |
| WIFI-6 AC1200 Full Router JIR-AC666R2 |
Specification parameters OF WIFI 6:
| Chipset |
RTL8197FH-VG4+RTL8812FR+RTL8367RB-VC |
| FLASH |
8MB |
| DDR2 |
64MB |
| Wireless rate |
2.4 GHz：300Mbps&2*2 |
| 5GHz：867Mbps&2*2 |
| Antenna |
4*5 dBi External antenna |
| Interface |
1* GE WAN+3* GE LAN |
| Button |
1* RESET+1* WPS |
| Indicator |
POWER WAN 2.4G 5G WPS |
| Wi-Fi Agreement |
IEEE 802.11b/g/n/ac support |
| MIMO modalities |
MU-MIMO |
| Work model |
Routing mode, AP mode, and relay mode |
| Management approach |
Chinese WEB Remote Management |
| State |
System state, interface state, and routing table |
| Wireless Configuration |
Wi-Fi Basic Parameter Configuration / Blacklist |
| Network settings |
Working mode: LAN/WAN address setting |
| System |
System properties/password modification/backup upgrade/restart |
| Setup Wizard |
Quick Configuration Wizard |
| MTBF |
>20000 H |
| power consumption |
≤9 W |
| Working temperature |
0℃～40℃ |
| Storage temperature |
-40℃～70℃ |
| Working humidity |
10%~95%, no condensation |
| Storage humidity |
5%~95%, no condensation |
| Power adapter |
DC 12V/1A |
