Drop Cable SC UPC to SC UPC
Visit the D-TECH Store
Contact for
Quote
.jpg)
About this item
- Optical Fiber Drop Cable
Technical Details
| More Details | 78-TRIAL-1 Full Carton contains 6 Rolls 59 |
| Weight | 159-TRIAL-5kg 149 |
| Lead Time | 24-TRIAL-China to Nepal 35-45Days 72 |
| Country of Origin | China |
| Package | 6 Rolls |
Contact for Price
Pricing based on order quantity
Trade Assurance
Built-in order protection
In Stock
FREE Delivery on eligible orders
Select a city to check delivery
Supplier Info
D-TECH
Verified Supplier
4.8 / 5.0 Response Rate
7-Day Returns
if defective or damaged
if defective or damaged
Warranty
Seller warranty (if applicable)
Seller warranty (if applicable)
Secure Payment
Multiple options available
Multiple options available
1 Core Drop Fiber Cable (G.657A1) – Technical Data
Cable Structure & Parameters
| Parameter | Specification |
|---|---|
| No. of Fiber | 1 Core |
| Fiber Model | G.657A1 |
| Messenger | Stranded Steel Wire (7×0.3mm / 0.9mm) |
| Strength Member | Steel Wire Ø0.4mm |
| Outer Sheath | LSZH, Black |
| Cable Diameter | 1.8 × 4.8 mm |
| Cable Weight | 15 kg/km |
Optical Performance
| Parameter | Value |
|---|---|
| Attenuation @1310nm | ≤ 0.40 dB/km |
| Attenuation @1550nm | ≤ 0.30 dB/km |
Mechanical Performance
| Parameter | Short Term | Long Term |
|---|---|---|
| Tensile Strength | 600 N | 300 N |
| Crush Resistance | 2200 N/100mm | 1000 N/100mm |
Temperature Range
| Condition | Range |
|---|---|
| Installation | -20°C ~ +60°C |
| Transport & Storage | -40°C ~ +60°C |
| Operation | -40°C ~ +60°C |
Patch Cord Specifications
| Parameter | Value |
|---|---|
| Insertion Loss | ≤ 0.2 dB |
| Return Loss (APC) | ≥ 60 dB |
| Return Loss (UPC) | ≥ 50 dB |
| Available Length | 30m, 50m, 75m, 100m, 125m, 150m, 200m, 300m |
Fiber Properties (ITU-T G.657A1)
| Parameter | Specification |
|---|---|
| Fiber Type | Single Mode |
| Attenuation | ≤ 0.35 dB/km @1310nm, ≤ 0.21 dB/km @1550nm |
| Cut-off Wavelength | ≤ 1260 nm |
| Dispersion | ≤ 18 ps/(nm·km) @1550nm |
