HSGQ-T131U is a high-performance XGSPON Optical Network Unit (ONU) designed for FTTH networks. It provides 10Gbps downstream and 10Gbps upstream capacity with integrated routing, Ethernet, and voice services. The device is widely compatible with global OLT brands and supports advanced management, security, and cloud control features.

Key Specifications

PON Interface

→ XGSPON Port: 1 × SC/APC
→ Transmission Distance: Up to 20 km
→ Downstream Wavelength: 1577 nm
→ Upstream Wavelength: 1270 nm
→ Downstream Rate: 9.953 Gbps
→ Upstream Rate: 9.953 Gbps
→ Optical Transmit Power: +5.5 ~ +7.5 dBm
→ Optical Receive Sensitivity: –29 dBm
→ Overload Optical Power: –8 dBm

Ethernet Interfaces

→ 1 × 10GE RJ45 LAN Port
→ 3 × GE RJ45 LAN Ports
→ Auto-negotiation: 10/100/1000M & 10G
→ Full/Half Duplex Mode
→ RJ45 Connector
→ Auto MDI/MDIX
→ Maximum Cable Distance: 30 meters

Voice (POTS) Interface

→ 1 × RJ11 Port
→ Maximum Ringing Voltage: 55V RMS
→ Ring Frequency: 25 Hz

USB Interface

→ 1 × USB Port

Supported Standards

→ ITU-T G.9807 (XGSPON)
→ ITU-T G.988 (OMCI Management)

Core Features

→ Supports OMCI and TR-069 remote management
→ Compatible with major global OLT brands
→ Dynamic Bandwidth Allocation (DBA)
→ VLAN configuration and port binding
→ QoS configuration and traffic control
→ ACL packet filtering and port isolation
→ Multicast and group broadcasting support
→ PPPoE / DHCP Server / IPTV / NAT
→ IPv4 / IPv6 support
→ Automatic ONU discovery and link detection
→ Online firmware upgrade and maintenance
→ Cloud management supported
→ System protection for stable long-term operation

Environmental Specifications

→ Operating Temperature: 0°C ~ 50°C
→ Storage Temperature: –40°C ~ 75°C
→ Operating Humidity: 0% ~ 85% (non-condensing)
→ Storage Humidity: 5% ~ 95% (non-condensing)

Power Specifications

→ Power Input: 12V DC
→ Power Interface: 2.1 mm / 5.5 mm
→ Power Consumption: < 12W

Physical Dimensions

→ Size: 160 mm × 110 mm × 30 mm (L × W × H)

Ordering Information

→ Model: HSGQ-T131U
→ Configuration:
  • 1 × XGSPON Port
  • 1 × 10GE RJ45
  • 3 × GE RJ45
  • 1 × POTS
  • 1 × USB
