1G-2SC-4POE+1 Uplink Fiber PoE Switch
Category
Specification
Product Name
4 GE + 2 SC Full Gigabit PoE Switch
Model
1G-2SC-4POE+1Uplink
Product Type
Unmanaged Gigabit PoE Fiber Switch
Ports
4 × 10/100/1000 Mbps RJ45 + 2 × SC Fiber
PoE Ports
Port 1–4 (IEEE 802.3af/at)
PoE Output
Up to 30W per port
Total PoE Power
56W (Max 72W)
Fiber Speed
1000 Mbps
Network Standards
IEEE 802.3, 802.3u, 802.3ab, 802.3az, 802.3x, 802.3af, 802.3at
Transmission Mode
Store & Forward
Backplane Bandwidth
12 Gbps
MAC Address Table
1K (Auto Learning & Updating)
RJ45 Features
Auto MDI/MDIX, Auto Negotiation
PoE Mode
Mode A (1/2+, 3/6-) / Optional 4/5+, 7/8-
Network Cable
Cat3–Cat6 (Up to 100m)
Power Input
DC 12V – 52V
Power Supply
External Adapter
Power Consumption
Depends on PoE load
LED Indicators
Power, PoE Status, Link/Activity
Energy Saving
IEEE 802.3az
Housing
Metal
Dimensions
149 × 94 × 28 mm
Weight
Net: 0.32 kg / Gross: 0.56 kg
Operating Temperature
0°C to +40°C
Storage Temperature
-40°C to +70°C
Humidity
10%–90% (Operating), 5%–90% (Storage)
Certification
CE, FCC
Installation
Desktop / Plug & Play
