PON Single-Mode 1625nm OTDR with VFL & Optical Power Meter
The D-TECH PON Single-Mode 1625nm OTDR is a compact, cost-effective optical fiber testing instrument specifically designed for FTTH, GPON, EPON, and PON network maintenance. Operating at a dedicated 1625nm wavelength, it performs accurate online fiber testing without interrupting live network traffic, making it ideal for troubleshooting active optical networks.
The unit integrates an Optical Time Domain Reflectometer (OTDR), Visual Fault Locator (VFL), and Optical Power Meter (OPM) into one portable device. It quickly detects fiber breaks, bends, splice loss, connector reflections, and attenuation events while providing simple operation, lightweight portability, and long battery life for field engineers.
Quick Specifications
Key Features
- Single-mode 1625nm OTDR optimized for FTTH & PON networks
- Online testing without interrupting live optical signals
- Accurate detection of fiber breaks and bending points
- Measures splice loss, attenuation and reflection events
- Clear distinction between loss and reflection events
- Integrated Optical Power Meter (OPM)
- Built-in Visual Fault Locator (VFL)
- Supports up to 1:64 splitter testing
- Stores up to 100 test records
- Simple operation without complicated configuration
- Compact lightweight design (~450 g)
- Powered by AA batteries, rechargeable battery or USB
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | TTWH1625 / TWH-6118 |
| OTDR Wavelength | 1625 nm (Single-Mode) |
| Dynamic Range | 40 dB / 35 dB |
| Splitter Support | 1:64 / 1:32 |
| Test Dead Zone | ≤ 3 m |
| Reflective Dead Zone | ≤ 10 m |
| Attenuation Dead Zone | < 30 m |
| Distance Resolution | 1 m |
| Pulse Width | 10 ns – 500 ns |
| Distance Accuracy | ±(0.8 m + 0.01% × Distance ± Resolution) |
| Loss Threshold | > 0.8 dB |
| Loss Resolution | 0.1 dB |
| Connector | FC/PC or SC/PC |
| OPM Wavelength | 850 / 1300 / 1310 / 1490 / 1550 / 1625 nm |
| OPM Measurement Range | -70 ~ +8 dBm or -50 ~ +26 dBm |
| VFL Output | 10 mW / 20 mW |
| Storage Capacity | 100 Test Groups |
| Display | 2.8-inch TFT Color Screen |
| Communication Port | Mini USB |
| Power Supply | AA Batteries / Rechargeable Battery / USB Power |
| Battery Life | Standby > 15 Hours Testing > 8 Hours |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Dimensions | 210 × 120 × 55 mm |
| Weight | Approximately 450 g |
Applications
FTTH & GPON Networks
Designed for installation, maintenance, and troubleshooting of FTTH and PON optical networks.
Live Fiber Testing
Performs online testing at 1625nm without interrupting active communication services.
Fiber Maintenance
Quickly locates fiber breaks, macro bends, connector faults, and splice loss.
ISP & Telecom
Suitable for broadband providers, telecom operators, CATV systems, and enterprise fiber networks.
Testing Recommendation
Use the dedicated 1625nm wavelength for online testing of live PON networks without interrupting service. Clean all optical connectors before testing to ensure accurate OTDR traces and power measurements. Utilize the integrated VFL for quick visual fault identification and the built-in Optical Power Meter to verify signal levels before and after maintenance activities.
