Audio to fiber converter Terminal port
2CH bidirectional
Variant Specifications
Warranty:
Weight:
Country of Origin:
More Details:
Import Lead Time:
Package:
4CH Un-bidirectional
Rs 5,467.80
Audio to Fiber Converter
The Audio to Fiber Converter uses advanced digital optical transmission technology to provide synchronous, distortion-free, and high-quality transmission over a single fiber. It supports audio, data, Ethernet, and telephone signals with stable and real-time performance.
| Category | Specification |
|---|---|
| Key Features |
Independent 2U rack design Uncompressed real-time transmission Gigabit fiber transmission High stability hardware design LED status indicators Supports SM/MM fiber FC / SC / ST interface Up to 120KM transmission (SM) Plug & Play installation |
| Signal Type | Data, Ethernet, Audio, Telephone |
| Channel | 1 Channel |
| Wavelength | 850nm / 1310nm / 1550nm |
| Output Power | -9.5 ~ -3 dBm |
| Sensitivity | -15 dBm |
| Fiber Port | FC / SC / ST (Single Fiber) |
| Distance |
Multi-mode: up to 2KM Single-mode: up to 10KM (standard) Optional: up to 120KM |
| Power Supply | DC 5V |
| Power Consumption | < 10W |
| Ethernet |
RJ45 (10/100 Mbps) IEEE 802.3 / 802.3u / 802.3ab / 802.3z |
| Data Interface |
RS-232 / RS-422 / RS-485 ≤ 384 Kbps |
| Audio |
Unbalanced audio (600Ω) 10Hz – 20kHz THD < 0.05% SNR > 95 dB |
| Telephone |
Hotline / PBX Bandwidth: 8KHz Distortion < 1% |
| Alarm / Control |
TTL / Passive switch Industrial terminal block |
| Operating Temp | 0°C to +55°C |
| Storage Temp | -20°C to +70°C |
| Humidity | 0% – 95% |
| MTBF | > 30,000 hours |
The Audio to Fiber Converter uses advanced digital fiber transmission technology for real-time, distortion-free audio and data transmission. It supports single or multimode fiber with a range of up to 120KM. Features include uncompressed signal transfer, multiple interface options (FC/SC/ST), and compatibility with Ethernet, data, audio, and telephone signals. It's reliable, easy to install, and ideal for versatile applications with stable performance in various environments.
