D-TECH SFP 10G BIDI Tx1270/Rx 1330nm DDM
Visit the D-TECH Store
-4%
Rs
24,000
.00
M.R.P.: Rs 25,000.00
Exclusive of all taxes
Technical Details
| Compatible | Cisco, Juniper, Huawei, Nokia |
| Warranty | 1 Year |
| Warranty | 1 Year |
| Country of Origin | China |
Rs 24,000.00
-4%
M.R.P. Rs 25,000.00
Excl. taxes
| Min. Order | Unit Price |
|---|---|
| 1 Piece | Rs 24,000.00 |
Trade Assurance
Built-in order protection
In Stock
FREE Delivery on eligible orders
Select a city to check delivery
Supplier Info
D-TECH
Verified Supplier
4.8 / 5.0 Response Rate
7-Day Returns
if defective or damaged
if defective or damaged
Warranty
Seller warranty (if applicable)
Seller warranty (if applicable)
Secure Payment
Multiple options available
Multiple options available
10G Optical Transceiver
Absolute Maximum Ratings
| Parameter | Min | Max | Unit |
|---|---|---|---|
| Power Supply Voltage | 0 | 3.6 | V |
| Storage Temperature | -40 | 85 | °C |
| Operating Case Temperature (Standard) | 0 | 70 | °C |
| Operating Case Temperature (Industrial) | -40 | 85 | °C |
| Relative Humidity | 5 | 95 | % |
| RX Input Average Power | - | 0 | dBm |
Recommended Operating Conditions
| Parameter | Min | Typ | Max | Unit |
|---|---|---|---|---|
| Power Supply Voltage | 3.135 | 3.3 | 3.465 | V |
| Power Supply Current | - | - | 350 | mA |
| Operating Case Temperature (Standard) | 0 | 25 | 70 | °C |
| Operating Case Temperature (Industrial) | -40 | 25 | 85 | °C |
Optical Characteristics
| Parameter | Value | Unit |
|---|---|---|
| Operating Reach | 60 km | m |
Transmitter
| Parameter | Value | Unit |
|---|---|---|
| Center Wavelength (Range) | 1270 / 1330 | nm |
| Side Mode Suppression Ratio (Min) | 30 | dB |
| Launched Power (Max Average) | 6 | dBm |
| Launched Power (Min Average) | 2 | dBm |
| Transmitter and Dispersion Penalty (Max) | 3.2 | dB |
| Average Launch Power of OFF Transmitter (Max) | -30 | dBm |
| Extinction Ratio (Min) | 3.5 | dB |
| RIN12 OMA (Max) | -128 | dB/Hz |
| Optical Return Loss Tolerance (Min) | 12 | dB |
Receiver
| Parameter | Value | Unit |
|---|---|---|
| Center Wavelength (Range) | 1270 / 1330 | nm |
| Receive Overload (Max Average Power) | -8 | dBm |
| Receive Sensitivity (Min Average Power) | -20 | dBm |
| Receiver Reflectance (Max) | -12 | dB |
| Vertical Eye Closure Penalty (Min) | 2.2 | dB |
| LOS Deassert (Max) | -27 | dBm |
| LOS Hysteresis (Min) | 0.5 | dB |
| Stressed Eye Jitter (Min) | 0.3 | UIp-p |
| Receive Electrical 3dB Upper Cutoff Frequency (Max) | 12.3 | GHz |
| Receiver Power Damage (Max) | 6 | dBm |
Digital Diagnostic Functions
| Parameter | Min | Max | Unit | Notes |
|---|---|---|---|---|
| Temperature Monitor Absolute Error | -3 | 3 | °C | Over operating temp |
| Laser Power Monitor Absolute Error | -3 | 3 | dB | - |
| RX Power Monitor Absolute Error | -3 | 3 | dB | -1dBm to -15dBm range |
| Supply Voltage Monitor Absolute Error | -0.08 | 0.08 | V | Full operating range |
| Bias Current Monitor | -10% | 10% | mA | - |
Electrical Characteristics
| Parameter | Min | Typ | Max | Unit |
|---|---|---|---|---|
| Data Rate | - | 10.3125 | - | Gbps |
| Power Consumption | 800 | - | 1000 | mW |
| TX Input Diff Voltage | 180 | - | 700 | mV |
| RX Output Diff Voltage | 300 | - | 850 | mV |
| RX Output Rise/Fall Time | 30 | - | - | ps |
