Product Specifications
|
|
|
Interface
|
1 x GPON
|
| |
4 x GE RJ45
|
| |
1: 10G SFP+
|
| |
ITUT G.984x3988
|
|
Password Authentication Modes
|
Terminal access
|
| |
Password authentication
|
|
Distance
|
Up to 60km on a single fiber
|
|
Split Ratio
|
1:128 split ratio on single PON port
|
|
DBA Algorithm
|
Particle for 64 Kbit/s
|
|
Management Functions
|
Standard OMCI management function
|
| |
ONU batch software upgrade
|
| |
PON port optical parameter detection
|
| |
Auto registration ONU bound with default profile
|
|
Memory
|
128MB
|
|
Flash
|
512MB
|
|
DDR Size
|
166mm x 157mm x 39mm
|
|
Weight
|
<5kg
|
|
Management Ports
|
Console port
|
|
Environment
|
Operating Temperature: -10°C - 55°C
|
| |
Storage Temperature: -40°C ~ 70°C
|
| |
Storage Humidity: 5%–95% (non-condensing)
|
|
Power Supply
|
DC 12V
|
|
Power Consumption
|
|
|
Platform Management Features
|
|
|
Version Release
|
Configuration and Management
|
| |
Status
|
| |
License Management
|
| |
Permission Management
|
| |
User Management
|
| |
CLI, WEB, SNMP, NMS, and CLOUD
|
| |
Software and Bootrom Upgrade by TFTP and FTP
|
| |
Chinese-English Command Prompt
|
| |
Ping and Debug Diagnosis
|
| |
UserLog/Alarm Management
|
|
PON Features
|
|
|
PON Status
|
Uplink Status
|
|
Performance Monitor
|
System Monitor
|
|
Key Features
|
|
|
MAC Address Table
|
16K MAC address table
|
|
DBA
|
Flexible DBA for up-and-down traffic speed control
|
|
Traffic Control
|
Port-based traffic control
|
| |
Traffic shaping
|
|
ONL Identification
|
Automatic identification, auto-discovery, and auto-registration
|
|
VLAN Support
|
Multicast support, IGMP snooping
|
|
Cloud Management
|
|
|
Product Advantages
|
|
|
Uplink Flexibility
|
Support for electrical and optical modules; flexible configuration according to networking needs
|
|
Optical Link Diagnosis
|
Warning mechanism for optical links
|
|
High Reliability
|
Dual power supply support
|
|
Dimension
|
TU cassette design saves space and has low power consumption
|
|
Capacity
|
Each PON supports up to 128 terminals; the whole device supports up to 128 ONUs under full configuration
|
|
Ordering Information
|
|
|
Product Model
|
HSGQ-G01
|
|
Description
|
1-GPON Part
|
| |
6-GE RJ45
|
| |
1-10G SFP+
|
