Product Features
PON Features
SN/SN+Password/LOID/LOIDPassword/LOID+LOID Password authentication modes;
DBA algorithm, and the particle is for 64Kbit/s;
Standard OMCl management function;
ONU batch software upgrade;
PON port optical parameter detection;
Auto registeration ONU bound with default profile
Security Features
User Security
Anti-ARP-spoofing;
Anti-ARP-flooding;
Port lsolation;
MAC address binding to the port and MA Caddress filtering;
Device Security
Support the control layer to prevent a variety of Dos attacks and virus attacks against the CPU;
Hierarchical management and password protectionof users;
SSHv2 Secure Shell;
Login Security IP via Telnet;
Network Security
User-based MAC and ARP traffic examination;
Restrict ARP traffic of each user and force-out user with abnormal ARP traffic;
Dynamic ARP table-based binding;
IP+VLAN+MAC+Port binding;
L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet;
Port-based broadcast/multicast suppression and auto-shutdown risk port;
DHCP Option82 and PPPoE+ upload user’sphysical location
Service Features
QoS
Rate-limit to packet sending/receiving speed of port or self-defined flow and provide general flow monitor and two-speed tri-color monitor of self-defined flow;
CAR(Committed Access Rate),Traffic Shaping and flow statistics;
Packet mirror and redirection of interface and self-defined flow;
Supports priority marking of ports or custom flows and provides 802.1p, DSCP-priority Remark capability;
Super queue scheduler based on port or self-defined flow. Each port/flow supports 8 priority queues and scheduler of SP, WRR andSP+WRR;
Congestion Avoidance Mechanism, including Tail-Drop and WRED;
ACL
Standard and extended ACL;
Time Range ACL;Flow classification and flow definition based onsource/destination MAC addressVLAN,802.1p, Tos, DiffServ, source/destination IP(IPv4/IPv6) address, TCP/UDP port numberprotocol type, etc;
packet filtration of L2～L7 deep to 80 bytes of IP packet head;
IPv4
DHCP Relay;
DHCP Server;
DHCP Snooping;
Static Routing;
Multicast
IGMPv1/v2/v3 Snooping;
IGMP Fast leave;
IGMP Proxy;
Maintenance
Network Maintenance
Port real-time, utilization and transmit/receive statistic
Powerful WEB GUI
Data Logging and RFC 3164 BSD syslog protocol;
Ping
Device Management
Console port, Telnet, SSH management;
Out-band management;
SNMPv1/v2
RMON(Remote Monitoring)1,2,3,9 groups MIB;
SNTP;
Fan management
L2 Features
MAC
MAC Black Hole;
Port MAC Limit;
64K MAC(packet exchange chip cache 2MB );
VLAN
4K VLAN entries;
Port-based VLAN classification;
Uplink VLAN Swap and VLAN Remark;
Spanning Tree
STP/RSTP/MSTP
Loop detection
Port
Support link aggregation;
Port mirroring;
Service Port
Auto configuration service-port by profile
VLAN transparent/tag/stacking/aggregation
Reliability
Loop Protection
Loopback-detection;
Link Protection
RSTP/MSTP(recover-time <1s);
Link aggregation (recover-time <10ms);
Device Protection
1+1 power hot backup;
Product Specification
Switching Capacity
67Gbps
4*PON port,4*GE RJ45,2*GE SFP port, 2*10GE SFP+ port
Redundancy Design
Dual power supply
Support double Ac input, double DC input and AC+DC input
Power Supply
AC: input 100～240V 50/60Hz;
Power Consumption
50W
Dimensions (Width x Depth x Height)
440mm ×44mm ×380mm
Weight(Full-Loaded)
≤5kg
Environmental Requirements
Working temperature: -10°C～55°C
Storage temperature: -40C～70C
Relative humidity: 10%～90%, non-condensing
Max Transmission Distance
Max Transmission Distance: 20km
Max TransmissionDistance
Max splitting Ratio: 1:128
