Fiber Optic Adapter
LC to LC UPC Dx 0db
Brand:
D-TECH
Variant Specifications
Warranty:
Size:
Weight:
Country of Origin:
Delivery Time (if import required):
LC to LC APC Dx 0db
LC UPC to LC UPC 5db
SC UPC to SC UPC 0db
FC UPC to FC UPC 0db
SC UPC to SC UPC 5db
LC to LC Dx OM4
SC to SC APC 0db
SC UPC to LC UPC 0db
1% OFF
Rs 65.22
List: Rs 65.70
LC to LC UPC Duplex 0dB Fiber Adapter
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Fiber Optical Adapter (Coupler) |
| Connector Type | LC Duplex to LC Duplex |
| Polish Type | UPC (Ultra Physical Contact) |
| Attenuation Value | 0 dB (Pass-through) |
| Fiber Type | Single Mode / Multimode |
| Insertion Loss | ≤ 0.2 dB |
| Return Loss | ≥ 50 dB (SM) / ≥ 35 dB (MM) |
| Sleeve Material | Ceramic |
| Housing Material | PBT + Glass Fiber |
| Color | Blue (SM) / Aqua (MM) |
| Mounting Type | Flange / Panel Mount |
| Durability | ≥ 500 Mating Cycles |
| Operating Temperature | -40°C to +75°C |
| Storage Temperature | -40°C to +85°C |
| Compliance Standards | IEC, RoHS |
Ask a question
Questions & answers
0 question(s)No questions yet. Be the first to ask!
0.0
5★
0
4★
0
3★
0
2★
0
1★
0
Write a review
Sign in to reviewCustomer reviews
No reviews yet. Be the first to review this product.
Product Videos
Watch demos, overviews and installation guides related to this product.
