D-TECH SFP 10G BIDI Tx1270/Rx 1330nm DDM

Name: D-TECH SFP 10G BIDI Tx1270/Rx 1330nm DDM
Brand: D-TECH
SKU: 188
Price: 24000.00 NPR
Availability: InStock

Visit the D-TECH Store

0.0

0 ratings

-4% Rs 24,000 .00

M.R.P.: ~~Rs 25,000.00~~

Exclusive of all taxes

Variation: 80KM LC

80KM LC

40km LC

10km LC

20km LC

60km LC

20km SC

Technical Details

Compatible	Cisco, Juniper, Huawei, Nokia
Warranty	1 Year
Warranty	1 Year
Country of Origin	China

Download Datasheet Save

SKU: #496 Category: Networking Goods

Rs 24,000.00 -4%

M.R.P. ~~Rs 25,000.00~~

Excl. taxes

Min. Order	Unit Price
1 Pair(2pcs)	Rs 24,000.00

Trade Assurance Built-in order protection

In Stock

FREE Delivery on eligible orders

Deliver to

Select a city to check delivery

Supplier Info

D-TECH

Verified Supplier

4.8 / 5.0 Response Rate

7-Day Returns
if defective or damaged

Warranty
Seller warranty (if applicable)

Secure Payment
Multiple options available

10G Optical Transceiver

10G SFP+ Optical Module • 10-60KM Reach • 1270 / 1330nm • DDM Supported

The 10G Optical Transceiver is designed for high-speed 10 Gigabit Ethernet optical transmission over single-mode fiber. With long-distance reach up to 60km, stable optical performance, and Digital Diagnostic Monitoring support, it is suitable for ISP backbone, telecom, enterprise, and data center network applications.

Data Rate

10.3125Gbps

Reach

10-60KM

Wavelength

1270/1330nm

Power

≤1000mW

Key Features

✔ Supports 10.3125Gbps high-speed optical transmission

✔ Long-distance operating reach up to 60km

✔ 1270nm / 1330nm wavelength option

✔ Standard and industrial temperature options

✔ Digital Diagnostic Monitoring supported

✔ Suitable for ISP, telecom, enterprise and data center networks

Absolute Maximum Ratings

Parameter	Min	Max	Unit
Power Supply Voltage	0	3.6	V
Storage Temperature	-40	85	°C
Operating Case Temperature (Standard)	0	70	°C
Operating Case Temperature (Industrial)	-40	85	°C
Relative Humidity	5	95	%
RX Input Average Power	—	0	dBm

Recommended Operating Conditions

Parameter	Min	Typ	Max	Unit
Power Supply Voltage	3.135	3.3	3.465	V
Power Supply Current	—	—	350	mA
Operating Case Temperature (Standard)	0	25	70	°C
Operating Case Temperature (Industrial)	-40	25	85	°C

Optical Characteristics

Parameter	Value	Unit
Operating Reach	60	km

Transmitter Specifications

Parameter	Value	Unit
Center Wavelength Range	1270 / 1330	nm
Side Mode Suppression Ratio Min	30	dB
Launched Power Max Average	6	dBm
Launched Power Min Average	2	dBm
Transmitter & Dispersion Penalty Max	3.2	dB
Average Launch Power of OFF Transmitter Max	-30	dBm
Extinction Ratio Min	3.5	dB
RIN12 OMA Max	-128	dB/Hz
Optical Return Loss Tolerance Min	12	dB

Receiver Specifications

Parameter	Value	Unit
Center Wavelength Range	1270 / 1330	nm
Receive Overload Max Average Power	-8	dBm
Receive Sensitivity Min Average Power	-20	dBm
Receiver Reflectance Max	-12	dB
Vertical Eye Closure Penalty Min	2.2	dB
LOS Deassert Max	-27	dBm
LOS Hysteresis Min	0.5	dB
Stressed Eye Jitter Min	0.3	UIp-p
RX Electrical 3dB Upper Cutoff Frequency Max	12.3	GHz
Receiver Power Damage Max	6	dBm

Digital Diagnostic Functions

Parameter	Min	Max	Unit	Notes
Temperature Monitor Absolute Error	-3	3	°C	Over operating temp
Laser Power Monitor Absolute Error	-3	3	dB	—
RX Power Monitor Absolute Error	-3	3	dB	-1dBm to -15dBm range
Supply Voltage Monitor Absolute Error	-0.08	0.08	V	Full operating range
Bias Current Monitor	-10%	10%	mA	—

Electrical Characteristics

Parameter	Min	Typ	Max	Unit
Data Rate	—	10.3125	—	Gbps
Power Consumption	800	—	1000	mW
TX Input Diff Voltage	180	—	700	mV
RX Output Diff Voltage	300	—	850	mV
RX Output Rise / Fall Time	30	—	—	ps

Applications: 10G Ethernet, ISP Backbone, Metro Network, Enterprise Fiber Links, Data Center Interconnect, Telecom Transmission and Long-Distance Optical Connectivity.
