800G Muxponder

Visit the D-TECH Store

0.0

0 ratings

Contact for Quote

Style Name: Select option

Download Datasheet Save

SKU: #27 Category: OFC Active Devices

Request a Quote

Ships from
D-TECH

Sold by
D-TECH

Deliver to

Select a city to check delivery availability

7 Day Replacement
if delivered defective or damaged

Warranty
Seller warranty (if applicable)

800G Muxponder Service Board: P716 – Specifications

Category	Details
Occupied Slot	2 slots
Line-side	- 1 × OSFP optical port (800G OSFP DCO module, pluggable) - Adjustable wavelength (range: 191.25 ~ 196.1 THz) - Adjustable light-emitting power (depends on optical module) - Supports 400 Gbit/s to 800 Gbit/s, programmable
Client-side	- 2 × QSFP-DD / QSFP28 compatible optical ports - 6 × QSFP28 optical ports, pluggable
Supported Service Types	400 GbE, 100 GbE
Loopback	Supports inner and outer loopback on line-side and client-side
LLDP	Receive mode only
ALS	Client-side support
Alarm Delay Insertion	Supports Local Fault alarm delay insertion function and delay time setting
Alarm and Performance Monitoring	- Line-side and client-side performance and alarm monitoring - Ethernet RMON monitoring - Optical module monitoring (temperature, current, optical power) - Telemetry support
Typical Power Consumption	< 120 W
