PoF MDU XPON ONU

HSGQ-F400P Industrial GPON / EPON PoF ONU

4× Gigabit PoE • GPON / EPON • Power over Fiber (PoF) • Industrial Grade

Product Overview

The HSGQ-F400P is an industrial GPON / EPON adaptive ONU designed for Power over Fiber (PoF) and remote PoE network applications.

It provides 4 Gigabit Ethernet PoE ports for connecting and powering IP cameras, wireless access points, industrial network equipment and other compatible PoE devices.

Quick Specifications

Model
HSGQ-F400P

PON Type
GPON / EPON Adaptive

PON Port
1 × SC Optical Port

Ethernet Ports
4 × Gigabit RJ45 PoE

PoE Output
Up to 30W Per Port

Total PoE Budget
Up to 120W

Input Voltage
48V – 57V DC

Operating Temperature
-30°C to +70°C

Key Features

✓ GPON & EPON auto-adaptive technology

✓ Supports Power over Fiber (PoF)

✓ 4 × Gigabit Ethernet PoE ports

✓ IEEE 802.3af / IEEE 802.3at PoE

✓ Maximum 30W PoE output per port

✓ Maximum 120W total PoE budget

✓ OMCI remote management

✓ VLAN, QinQ, Trunk & VLAN Translation

✓ IGMP multicast / IPTV support

✓ IPv4 / IPv6 compatible

✓ Cloud management support

✓ Industrial wide-temperature operation

PON Specifications

GPON Downstream:
2.5Gbps

GPON Upstream:
1.25Gbps

EPON Downstream:
1.25Gbps

EPON Upstream:
1.25Gbps

Transmit Optical Power:
0 to +4 dBm

GPON Receive Optical Power:
-7 to -28 dBm

EPON Receive Optical Power:
-7 to -27 dBm

PoE Specifications

PoE Standard:
IEEE 802.3af / IEEE 802.3at

PoE Ports:
4 × Gigabit Ethernet RJ45

Maximum Per Port:
30W

Total PoE Power:
120W Maximum

PoE Pin Assignment:
1/2 (+), 3/6 (-)

Power Input:
48V – 57V DC

Maximum Power Consumption:
<130W

Physical & Environmental

Dimensions:
190 × 85 × 28 mm

Operating Temperature:
-30°C to +70°C

Operating Humidity:
0% – 85% RH, Non-condensing

Storage Temperature:
-40°C to +80°C

Storage Humidity:
5% – 95% RH, Non-condensing

Network & Management

ONU Management:
OMCI Remote Management

VLAN:
VLAN, QinQ, Trunk & VLAN Translation

Multicast:
IGMP / IPTV Support

IP Support:
IPv4 / IPv6

Cloud:
Cloud Management Supported

LED Indicators

PWR: Power Status

PON: ONU Registration Status

LOS: Optical Signal Status

LAN: Ethernet Link Status

PoE: PoE Power Status

Applications

✓ Power over Fiber (PoF) Networks

✓ Outdoor CCTV & IP Cameras

✓ Remote Wireless Access Points

✓ Industrial Ethernet Networks

✓ Smart City Infrastructure

✓ ISP & Telecom Networks

✓ Remote PoE Device Deployment

✓ Industrial IoT Applications

PoF Installation Note

Power over Fiber deployments require suitable optical composite cable, power equipment and correct voltage selection. Please confirm the complete PoF system design before installation.
