Air Blown Micro Fiber Cable
1*96 Core 11mm
Variant Specifications
Warranty:
Weight:
Country of Origin:
More Details:
Package:
Lead Time:
Available options
Rs 2.00
Air Blown Fiber Cable – Optical Fiber Technical Specifications
| Fiber Type | ITU-T G.652 Single-Mode Fiber |
| Application | Air Blown Fiber (Micro-duct installation) |
Geometrical Characteristics
| Parameter | Specification |
|---|---|
| Core Non-Circularity | ≤ 6% |
| Cladding Diameter | 125.0 ± 0.7 μm |
| Core / Cladding Concentricity Error | ≤ 0.6 μm |
| Cladding Non-Circularity | ≤ 1.0% |
| Coating Diameter | 245 ± 10 μm |
| Coating / Cladding Concentricity Error | ≤ 12 μm |
Optical Performance
| Parameter | Specification |
|---|---|
| Attenuation @ 1310 nm | ≤ 0.35 dB/km |
| Attenuation @ 1550 nm | ≤ 0.21 dB/km |
| Zero Dispersion Wavelength | 1300 – 1324 nm |
| Zero Dispersion Slope | ≤ 0.092 ps/(nm²·km) |
| Polarization Mode Dispersion (PMD) | ≤ 0.20 ps/√km |
| Mode Field Diameter @ 1310 nm | 9.0 ± 0.4 μm |
| Cut-off Wavelength | 1170 – 1330 nm |
Chromatic Dispersion
| Wavelength | Dispersion Value |
|---|---|
| 1288 – 1339 nm | ≤ 3.4 ps/(nm·km) |
| 1550 nm | ≤ 18 ps/(nm·km) |
| 1625 nm | ≤ 22 ps/(nm·km) |
