Cassette SC/UPC
1*4
Brand:
D-TECH
Variant Specifications
Warranty:
Size:
Delivery Time (if import required):
Country of Origin: China
Weight: 0.100 Kg
1*2
1*8
1% OFF
Rs 533.63
List: Rs 537.61
PLC Splitter 1×4 Cassette Type
Technical Specifications
| Category | Specification |
|---|---|
| Product Type | PLC Splitter (Cassette Type) |
| Configuration | 1 × 4 |
| Fiber Type | Single Mode G.657A1 / G.652D |
| Operating Wavelength | 1260 ~ 1650 nm |
| Insertion Loss (P Grade) | ≤ 7.0 dB |
| Insertion Loss (S Grade) | ≤ 7.3 dB |
| PDL | ≤ 0.3 dB |
| Loss Uniformity | ≤ 0.8 dB |
| Return Loss | ≥ 55 dB (P Grade) / ≥ 50 dB (S Grade) |
| Directivity | ≥ 55 dB |
| Connector Type | SC/UPC (Optional SC/APC) |
| Cable Length | 1.0 m (Customizable) |
| Fiber Diameter | 0.9 mm / 2.0 mm |
| Housing Type | ABS Cassette / LGX Box |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Dimension (L × W × H) | ~100 × 80 × 10 mm |
