Switch SFP 10G HSGQ-5912
Single AC Power
Brand:
HSGQ
Variant Specifications
Compatible:
Warranty:
Weight:
Country of Origin:
Import Lead Time:
Package:
Available options
1% OFF
Rs 30,831.79
List: Rs 31,061.93
12 Port 10G L3 Managed Industrial Switch
The HSGQ-5912 is a high-performance Layer 3 Managed Industrial Switch designed for enterprise networks, data centers, hotels, office networks, ISP infrastructure, and campus deployments. It supports advanced Layer 2 and Layer 3 features with powerful management, security, VLAN, QoS, multicast, and routing functions.
Featuring 12 × 10G SFP+ ports, cloud management support, high switching capacity, and industrial-grade reliability, the switch provides stable and secure high-speed network connectivity for modern optical networking environments.
Key Features
- 12 × 10G SFP+ high-speed optical ports
- Advanced Layer 3 managed switching
- Support for VLAN, QinQ, and multicast
- Cloud management and remote monitoring
- IPv4 & IPv6 support
- Static routing, RIP, and OSPF support
- Industrial-grade reliability and protection
- Supports STP, RSTP, MSTP protocols
- QoS traffic prioritization and flow control
- High switching capacity with non-blocking architecture
Hardware Specifications
| Category | Specification |
|---|---|
| Model | HSGQ-5912 |
| Port Configuration | 12 × 10G SFP+ |
| Console Port | 1 × RS-232 (115200, 8, N, 1) |
| Switching Capacity | 240 Gbps (Non-blocking) |
| Packet Forwarding Rate | 179 Mpps |
| Packet Buffer | 16 Mbit |
| MAC Address Table | 32K |
| Jumbo Frame | 12 KB |
| Input Voltage | AC 100V – 240V, 50Hz / 60Hz |
| Power Consumption | < 40W |
| ESD Protection | 8kV Contact Discharge, 15kV Air Discharge |
| MTBF | 100000 Hours |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% (Non-condensing) |
| Dimensions | 445 × 220 × 44 mm (W × D × H) |
| Weight | 1.7 Kg |
| Material | Metal Housing |
| Installation | Desktop / Rack-mounted / DIN-Rail / Wall Mounted |
Software Features
| Feature Category | Supported Functions |
|---|---|
| Basic Functions | Hardware watchdog, factory reset, system LED, port statistics, user management, alarm management, port mirroring, duplex control, MTU configuration, port speed limiting, WEB/Telnet access. |
| Cloud Management | Remote management, online upgrade, alarm monitoring, remote restart. |
| Layer 3 Features | ARP Table, ND Discovery, IPv4/IPv6 configuration, Static Routing, RIP, OSPF. |
| DHCP Features | DHCP Server, DHCP Relay, DHCP Snooping, DHCPv6 support, DHCP Option82. |
| VLAN Features | Access, Trunk, Hybrid VLAN, VLAN Translation, QinQ, 4K VLAN support, Port-based VLAN. |
| Security Features | HTTPS, SSH V1/V2, 802.1X authentication, port isolation, loop detection, AAA, TACACS+, RADIUS support. |
| QoS Features | 8-port queues, DSCP priority, SP & WRR scheduling algorithms, QoS re-marking. |
| STP Protocols | STP, RSTP, MSTP, BPDU protection. |
| Multicast Features | IGMP v1/v2/v3 Snooping, Layer 2 & Layer 3 multicast. |
| Link Aggregation | Static aggregation, LACP dynamic aggregation, up to 8 aggregation groups. |
| Management & Maintenance | SNMP V1/V2/V3, WEB Management, CLI, Syslog, CPU & Memory Monitoring, Ping & Traceroute. |
Applications
- Enterprise Networks
- Data Centers
- Hotels & Resorts
- Campus Networks
- ISP Infrastructure
- Industrial Networking
- Fiber Backbone Aggregation
- High-Speed Optical Networking
Note: Proper airflow, rack installation, and industrial grounding are recommended for stable 10G network performance and long-term reliability.
