| Model | HSGQ-TC08 |
| Product Type | XGSPON Combo OLT (GPON + XG-PON + XGS-PON) |
| Application | FTTH, Enterprise, ISP, Industrial Parks, Smart Buildings |
| Interface |
8 × XGSPON / XG-PON / GPON Ports |
| Uplink Ports |
4 × 10/25G SFP+ / SFP28
1 × 40/100G QSFP+ / QSFP28
|
| PON Port Type | SFP+ Slot (22-pin) |
| PON Standard |
ITU-T G.984 / G.987 / G.9807.1 |
| Split Ratio | 1:256 (Max), 1:128 (Recommended) |
| XGSPON Speed |
Upstream: 9.953 Gbps @1270 nm
Downstream: 9.953 Gbps @1577 nm
|
| XGPON Speed |
Upstream: 2.488 Gbps @1270 nm
Downstream: 9.953 Gbps @1577 nm
|
| GPON Speed |
Upstream: 1.244 Gbps @1310 nm
Downstream: 2.488 Gbps @1490 nm
|
| Flash Memory | 32 MB |
| DDR Memory | 1 GB |
| Dimensions | 442 × 393 × 44 mm (1U) |
| Management Ports |
1 × ETH Outbound, 1 × Console Serial |
| Power Supply |
AC 100–240V, 50–60Hz
Dual Power Optional (Hot-swappable)
|
| Power Consumption | < 160 W |
| Environment |
Operating: -10°C to +55°C
Storage: -40°C to +80°C
Humidity: 10% – 95% (Non-condensing)
|
| DBA | Dynamic Bandwidth Allocation Supported |
| ONU Management |
Auto Discovery, Authentication, White/Black List |
| VLAN | Transparent, Translation, QinQ |
| Multicast | IGMP Snooping / Proxy |
| L2 Features |
Port Isolation, MSTP, RSTP, ERPS, LLDP, LACP |
| L3 Features |
DHCP, Static Routing, OSPF, RIP, VRRP, PIM |
| QoS & Security |
ACL, QoS, Traffic Control |
| Cloud Management |
Project, Version, License, Alarm Management |
| Configuration |
CLI, Web, SNMP, NMS, Cloud |
| Monitoring |
Log, Alarm, Debug, Ping |
| Firmware Upgrade | Supported |
