XGSPON OLT - HSGQ
Variant Specifications
XGSPON- TC08
XGSPON-T02
HSGQ 4-Port XG(S)-PON Combo OLT
The HSGQ 4-Port XG(S)-PON Combo OLT is a next-generation Optical Line Terminal designed for high-performance FTTH, FTTB, enterprise, ISP, apartment, hotel, and campus fiber access networks. Supporting XGS-PON, XG-PON, and GPON technologies on a single platform, it provides a smooth migration path from GPON to 10G PON services without replacing existing optical infrastructure.
Equipped with 4 Combo PON ports, 4 × 10G SFP+ uplinks, Gigabit Ethernet interfaces, USB, and Type-C console management, the OLT delivers reliable broadband services while supporting centralized ONU management, cloud operation, and advanced Layer 2 and Layer 3 networking.
Designed for medium-sized fiber deployments, the HSGQ 4-Port Combo OLT combines high bandwidth, intelligent bandwidth allocation, cloud management, and comprehensive network security to build scalable and future-ready optical access networks.
Quick Specifications
Key Features
- 4 × XGS-PON / XG-PON / GPON Combo PON ports
- 4 × 10G SFP+ uplink ports
- 4 × Gigabit Ethernet ports
- 1 × GE Type-C interface
- 1 × USB 2.0 port
- 22-pin PON SFP+ slot
- Supports XG(S)-PON Class N1 / N2
- Supports GPON Class C++ / C+++ optics
- Maximum split ratio 1:128
- Automatic ONU registration
- ONU white list and black list
- Dynamic Bandwidth Allocation (DBA)
- Cloud, CLI, Web and SNMP management
- Advanced Layer 2 & Layer 3 routing
- Firmware, log and alarm management
- Supports QinQ, QoS and multicast services
Applications
FTTH & FTTB
Reliable fiber broadband deployment for residential and commercial subscribers.
Internet Service Providers
Medium-capacity optical access platform supporting GPON and XGS-PON migration.
Enterprise Networks
Centralized fiber infrastructure for offices, hotels, hospitals, schools and campuses.
Smart Buildings
High-speed optical access for apartments, smart communities and industrial parks.
Technical Specifications
| Category | Specification |
|---|---|
| Product Type | XG(S)-PON / XG-PON / GPON Combo OLT |
| Interface | 4 × XGSPON / XG-PON / GPON Ports 4 × GE RJ45 1 × GE Type-C 4 × 10G SFP+ 1 × USB 2.0 |
| PON Port | 22-pin PON SFP+ Slot |
| PON Type | XG(S)-PON Class N1 / N2 GPON Class C++ / C+++ |
| Maximum Split Ratio | 1 : 128 |
| XGS-PON Bandwidth | Upstream 9.953 Gbps @1270 nm Downstream 9.953 Gbps @1577 nm |
| XG-PON Bandwidth | Upstream 2.488 Gbps @1270 nm Downstream 9.953 Gbps @1577 nm |
| GPON Bandwidth | Upstream 1.244 Gbps @1310 nm Downstream 2.488 Gbps @1490 nm |
| Flash Memory | 32 MB |
| DDR Memory | 512 MB |
| Dimensions | 440 × 262 × 44 mm |
| Management Ports | 1 × GE/ETH Inbound/Outbound 1 × Type-C Console |
| Power Supply | AC 100–240V, 50/60Hz DC 12V / DC 48V |
| Power Consumption | <50 W |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +80°C |
| Humidity | 10% – 95% (Non-condensing) |
Network & Management Features
| Feature | Description |
|---|---|
| PON Features | Auto Registration, ONU White/Black List, DBA Configuration, P2P |
| Cloud Management | Device List, Project Management, Version Release, License Management, Alarm List |
| Configuration | CLI, Web, SNMP/NMS, Cloud |
| Monitoring | Firmware Upgrade, Ping & Debug, User / Log / Alarm Management |
| VLAN Features | Transparent, Translation, QinQ |
| Multicast | IGMP Snooping / Proxy |
| Layer 2 Features | Port Isolation, MSTP, RSTP, ERPS, LLDP, LACP |
| Layer 3 Features | DHCP, Static Route, OSPF, RIP, VRRP, PIM |
Installation Recommendation
The HSGQ 4-Port XG(S)-PON Combo OLT is ideal for medium-sized FTTH and enterprise fiber networks requiring GPON and 10G PON migration on a single platform. For optimal performance, design the network with an appropriate optical power budget, configure Dynamic Bandwidth Allocation (DBA), VLAN, multicast, QoS, and routing policies, and maintain a maximum split ratio of 1:128 for reliable long-term network performance.
