EXFO OTDR
MAX-715D-SM1
Variant Specifications
Warranty:
Weight:
Origin:
Import Lead Time:
Package:
Available options
750C
4% OFF
Rs 343,750.00
List: Rs 357,500.00
OTDR Max 715D
OTDR Specifications
| Category | Specification |
|---|---|
| Display | 7" outdoor touchscreen, 800 × 480 TFT |
| Interfaces | 2 × USB 2.0, RJ45 LAN (10/100 Mbps) |
| Storage | 2 GB (≈20,000 OTDR traces) |
| Battery | Li-polymer, up to 12 hours |
| Power Supply | 100–240 VAC / 9–16 V DC IN (15W min) |
| Wavelength | 1310 ±30 / 1550 ±30 / 1650 ±15 nm |
| Live Wavelength | 1650 nm (50 dB isolation) |
| Dynamic Range | 32 / 30 / 30 dB |
| Event Dead Zone | 0.9 m |
| Attenuation Dead Zone | 3.6 m |
| Distance Range | 0.1 – 200 km |
| Pulse Width | 3 – 20,000 ns |
| Linearity | ±0.05 dB/dB |
| Loss Threshold | 0.01 dB |
| Loss Resolution | 0.001 dB |
| Sampling Resolution | 0.04 – 5 m |
| Sampling Points | Up to 256,000 |
| Distance Uncertainty | ±(0.75 + 0.005% × distance + sampling resolution) |
| Measurement Time | User-defined |
| Reflectance Accuracy | ±2 dB |
| Real-Time Refresh | 3 Hz |
In-Line Power Checker
| Power Range | -60 to +23 dBm |
| Power Uncertainty | ±0.5 dB |
| Calibrated Wavelengths | 1310, 1490, 1550, 1625, 1650 nm |
| Selectable Wavelengths | 1270 – 1650 nm |
| Tone Detection | CW, 270 Hz, 330 Hz, 1 kHz, 2 kHz |
PON Power Meter (Optional)
| Power Range | -60 to +23 dBm |
| PON Channels | 1490/1550 and 1490/1577 nm |
| Power Uncertainty | ±0.5 dB |
| Calibrated Wavelengths | 1310, 1490, 1550, 1625, 1650 nm |
| Selectable Wavelengths | 1310, 1490, 1550, 1577, 1625, 1650 nm |
